Volkswagen Tiguan I (2007-2011) fuse panel c (lower left end of Wiring diagrams
This page contains all the electrical diagrams for the component. fuse panel c (lower left end of, in which he is found in the car Volkswagen Tiguan I (2007-2011). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram fuse panel c (lower left end of (1 of 2)
A/C CONTROL MODULE
ABS CONTROL MODULE ABS HYDRAULIC UNIT
ALARM HORN
ALARM HORN RELAY
AUXILIARY HEATER FUEL PUMP RELAY (IF EQUIPPED)
BLK WIRE
BLU WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
DASH)
DATA LINK CONNECTOR
DRIVER'S DOOR CONTROL MODULE
ELECTRO- MECHANICAL PARKING BRAKE BUTTON
ELECTRO- MECHANICAL PARKING BRAKE CONTROL MODULE
FRESH AIR BLOWER RELAY
FROM FUSE 48 (DIAGRAM 2 OF 5)
FROM FUSE PANEL A (DIAGRAM 1 OF 5)
FROM FUSE PANEL C (DIAGRAM 3 OF 5)
FRONT PASSENGER'S DOOR CONTROL MODULE
FUSE 20
FUSE 22
FUSE 23
FUSE 24
FUSE 40 FUSE 39 FUSE 41
FUSE 42
FUSE 43
FUSE 44 FUSE 21
FUSE 45
FUSE 46
FUSE 47
FUSE PANEL C (LOWER LEFT END OF
GRN WIRE
GRY WIRE
IGNITION SWITCH KEY LOCK SOLENOID (6 SPEED A/T)
IGNITION/STARTER SWITCH
INTERIOR MONITORING SENSOR
LIGHT SWITCH
MAGNETIC FIELD SENSOR
NCA WIRE
POWER SUNROOF CONTROL MODULE
RAIN/LIGHT RECOGNITION SENSOR
REAR VIEW CAMERA SYSTEM CONTROL MODULE
RED WIRE
RIGHT LEFT REAR REAR DOOR DOOR CONTROL CONTROL MODULE MODULE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE
TO FUSE PANEL C (DIAGRAM 3 OF 5)
TOWING RECOGNITION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (3 of 5) -> FUSE PANEL C (LOWER LEFT END OF
Wiring diagram fuse panel c (lower left end of (2 of 2)
A/C CONTROL MODULE
AUXILIARY HEATER OPERATION RELAY
BLK WIRE
BLOCKING DIODE
BLU WIRE
BRN WIRE
CIGARETTE LIGHTER
CONVERTER W/ SOCKET,
DASH)
DATA LINK CONNECTOR
DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER
DRIVER'S SEAT ADJUSTMENT CONTROL MODULE
DRIVER'S SEAT ADJUSTMENT SWITCH
DRIVER'S SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH
ELECTRONIC DAMPING CONTROL MODULE
FROM FUSE PANEL B (DIAGRAM 2 OF 5)
FROM TIPTRONIC SWITCH (DIAGRAM 3 OF 5)
FUSE 15
FUSE 25
FUSE 28
FUSE 29
FUSE 30
FUSE 33
FUSE 36
FUSE 37
FUSE 57
FUSE 58
FUSE PANEL C (LOWER LEFT END OF
FUSE PANEL C (LOWER LEFT END OF DASH)
FUSE PANEL C FUSE 38 (LOWER LEFT END OF DASH)
GRN WIRE
GRY WIRE
HEADLAMP RANGE/ CORNERING LAMP CONTROL MODULE
MASS AIR FLOW (MAF SENSOR)
MULTI- FUNCTION TRANSMISSION RANGE (TR) SWITCH
NCA WIRE
REAR WINDOW WIPER MOTOR
RED WIRE
ROOF BLIND CONTROL MODULE
SOCKET 3
SOCKET SOCKET 2
TO FUSE 16 (DIAGRAM 5 OF 5)
TO LOAD REDUCTION RELAY (DIAGRAM 5 OF 5)
TRAILER COUPLING LOCKED INDICATOR LAMP
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
W/ MEMORY
W/O MEMORY
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (4 of 5) -> FUSE PANEL C (LOWER LEFT END OF
