Volkswagen Tiguan I (2007-2011) electro- mechanical power steering indicator lamp instrument cluster Wiring diagram
This page shows the only wiring diagram for the component.electro- mechanical power steering indicator lamp instrument cluster, which is found in the car Volkswagen Tiguan I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electro- mechanical power steering indicator lamp instrument cluster (1 of 1)
12 13 COMPUTER DATA LINES SYSTEM
BLK WIRE
BLK/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
ELECTRO- MECHANICAL POWER STEERING INDICATOR LAMP INSTRUMENT CLUSTER
ELECTRO- MECHANICAL POWER STEERING MOTOR
FUSE 14 (LOWER LEFT END OF DASH)
FUSE PANEL C
HOT AT ALL TIMES FUSE PANEL A FUSE 2 (LEFT SIDE OF ENGINE COMPT)
HOT W/ POWER SUPPLY RELAY 2 (TERMINAL 15) ENERGIZED
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
POWER STEERING CONTROL MODULE (INTEGRAL W/ STEERING GEAR ASSEMBLY)
RED WIRE
STEERING ANGLE SENSOR (ON STEERING COLUMN)
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (UNDER STEERING COLUMN)
STEERING TORQUE SENSOR
WHT WIRE
YEL WIRE
