Volkswagen Tiguan I (2007-2011) center flap motor, position sensor Wiring diagram
This page shows the only wiring diagram for the component.center flap motor, position sensor, which is found in the car Volkswagen Tiguan I (2007-2011). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram center flap motor, position sensor (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN/WHT WIRE
CENTER FLAP MOTOR, POSITION SENSOR
CLIMATRONIC CONTROL MODULE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/RED WIRE
GRN/VIO WIRE
GRY WIRE
GRY/BLU WIRE
GRY/GRN WIRE
GRY/YEL WIRE
RIGHT TEMPERATURE FLAP POTENTIOMETER/ ACTUATOR, MOTOR (BEHIND CENTER OF DASH)
VIO/WHT WIRE
VIO/YEL WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/YEL WIRE
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Automatic a/c circuit (2 of 3) -> CENTER FLAP MOTOR, POSITION SENSOR
