Volkswagen Tiguan X II facelift (2020-2024) Cooling fan circuit

BLK WIRE BLK/RED WIRE BRN WIRE BRN/GRN WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM COOLANT SHUT-OFF VALVE ENGINE COOLANT LEVEL SENSOR ENGINE COOLANT TEMPERATURE SENSOR ENGINE COOLANT TEMPERATURE SENSOR ON RADIATOR OUTLET ENGINE/MOTOR CONTROL MODULE FUSE 17 FUSE 4 FUSE 42 FUSE 5 FUSE 7 FUSE PANEL A FUSE PANEL B GRN/GRY WIRE HOT AT ALL TIMES HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT NCA WIRE ORG/BLK WIRE ORG/BRN WIRE ORG/GRN WIRE OUTSIDE AIR TEMPERATURE SENSOR (LEFT SIDE OF GRILLE) RADIATOR FAN RADIATOR FAN 2 RADIATOR FAN CONTROL MODULE (RADIATOR FAN ASSEMBLY) RED/BLK WIRE RED/BLU WIRE RED/GRN WIRE VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO/RED WIRE WINDSHIELD WASHER FLUID LEVEL SENSOR YEL/GRY WIRE YEL/VIO WIRE
