Volkswagen Teramont I facelift (2021-2024) usb charging socket fuse Wiring diagram
This page shows the only wiring diagram for the component.usb charging socket fuse, which is found in the car Volkswagen Teramont I facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram usb charging socket fuse (1 of 1)
ABS CONTROL MODULE
BATTERY
BATTERY MONITORING CONTROL MODULE
BLK WIRE
BLK/RED WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
ELECTRIC TRAILER BRAKE POSITION SENSOR
FROM FUSE PANEL A (DIAGRAM 1 OF 5)
FROM FUSE PANEL C (DIAGRAM 3 OF 5)
FROM FUSE PANEL C (DIAGRAM 4 OF 5)
FUSE 1
FUSE 14
FUSE 18
FUSE 2
FUSE 3
FUSE 4
FUSE 5
FUSE 6
FUSE E
FUSE G
FUSE J
FUSE K
FUSE L
FUSE PANEL 1
FUSE PANEL A
GENERATOR W/ VOLTAGE REGULATOR
GRY WIRE
NCA WIRE
POWER STEERING CONTROL MODULE
RADIATOR FAN
RED WIRE
RED/BLK WIRE
RED/GRN WIRE
RED/VIO WIRE
RED/WHT WIRE
RED/YEL WIRE
REMOTE START SYSTEM RELAY
STARTER
STARTER RELAY 1
STARTER RELAY 2
TO FUSE 19 (DIAGRAM 2 OF 5)
TO FUSE PANEL C (DIAGRAM 3 OF 5)
TO FUSE PANEL C (DIAGRAM 5 OF 5)
TO POWER STEERING CONTROL MODULE (DIAGRAM 1 OF 5)
TRAILER CIRCUIT BREAKER
USB CHARGING SOCKET 1
USB CHARGING SOCKET 2
USB CHARGING SOCKET FUSE
W/ ENGINE REMOTE START
WINDSHIELD DEFOGGER RELAY RELAY & FUSE PANEL 5
Go to component -> Power distribution circuit (1 of 5) -> USB CHARGING SOCKET FUSE
