Volkswagen Teramont I facelift (2021-2024) steering wheel heating indicator lamp Wiring diagram
This page shows the only wiring diagram for the component.steering wheel heating indicator lamp, which is found in the car Volkswagen Teramont I facelift (2021-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram steering wheel heating indicator lamp (1 of 1)
BLK/GRY WIRE
BLK/YEL WIRE
BRN WIRE
CENTER INSTRUMENT PANEL SWITCH MODULE
COMPUTER DATA LINES SYSTEM
EXCEPT CROSS SPORT CROSS SPORT
FUSE 2
FUSE 26
FUSE PANEL C
HEATED STEERING WHEEL
HEATED STEERING WHEEL HEATER
HEATED STEERING WHEEL SENSOR
HOT AT ALL TIMES
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
STEERING COLUMN ELECTRONICS CONTROL MODULE
STEERING WHEEL HEATING BUTTON
STEERING WHEEL HEATING INDICATOR LAMP
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLU WIRE
YEL WIRE
Go to component -> Heated steering wheel circuit, w/o multi-function steering wheel -> STEERING WHEEL HEATING INDICATOR LAMP
