Volkswagen Teramont I (2017-2021) selector lever transmission range position display unit Wiring diagrams
This page contains all the electrical diagrams for the component. selector lever transmission range position display unit, in which he is found in the car Volkswagen Teramont I (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram selector lever transmission range position display unit (1 of 2)
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 2
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 3
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 4
AUTOMATIC TRANSMISSION PRESSURE REGULATING VALVE 6
BLK/GRN WIRE
BLK/RED WIRE
BLU WIRE
BLU/BLK WIRE
BLU/BRN WIRE
BLU/GRN WIRE
BLU/GRY WIRE
BLU/RED WIRE
BLU/VIO WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
FUSE 6
FUSE PANEL C
GRN/BLK WIRE
GRN/BRN WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
INTERIOR
LIGHTS)
ORG/BRN WIRE
ORG/GRN WIRE
RED/BLU WIRE
RED/YEL WIRE
SELECTOR LEVER
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
SELECTOR MECHANISM
SHIFT LOCK SOLENOID
STARTING/CHARGING SYSTEM
SYSTEM
TRANSMISSION
TRANSMISSION CONTROL MODULE
TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
VIO/BRN WIRE
VIO/GRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
W/ ENGINE REMOTE START W/O ENGINE REMOTE START
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
YEL WIRE
YEL/WHT WIRE
Go to component -> A/t circuit (2 of 3) -> SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
Wiring diagram selector lever transmission range position display unit (2 of 2)
2.0L TURBO 3.6L W/O ENGINE REMOTE START W/ ENGINE REMOTE START
BACKUP SWITCH
BLK/GRN WIRE
BLK/RED WIRE
BLU/VIO WIRE
BOTTOM LEFT COUPLING POINT IN INTERIOR
BRAKE LAMP SWITCH (ON BRAKE MASTER CYLINDER)
BRN WIRE
BRN/BLU WIRE
COMPUTER DATA LINES SYSTEM
ENGINE/MOTOR CONTROL MODULE
FUSE 13
FUSE 6
FUSE PANEL 1
FUSE PANEL B
FUSE PANEL C
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
GRY/BLU WIRE
GRY/RED WIRE
HOT AT ALL TIMES
HOT W/ MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ENERGIZED
IGNITION SWITCH KEY LOCK SOLENOID
IGNITION/STARTER SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED/YEL WIRE
REMOTE START SYSTEM RELAY
SELECTOR LEVER
SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
SELECTOR MECHANISM
SHIFT LOCK SOLENOID
STEERING COLUMN ELECTRONICS CONTROL MODULE
TOP OF TRANSMISSION)
TRANSMISSION CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/BLK WIRE
VIO/BRN WIRE
VIO/RED WIRE
VIO/WHT WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/GRY WIRE
WHT/RED WIRE
WHT/VIO WIRE
WHT/YEL WIRE
Go to component -> Shift interlock circuit -> SELECTOR LEVER TRANSMISSION RANGE POSITION DISPLAY UNIT
