Volkswagen Teramont I (2017-2021) right third row reading lamp button Wiring diagram
This page shows the only wiring diagram for the component.right third row reading lamp button, which is found in the car Volkswagen Teramont I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right third row reading lamp button (1 of 1)
BRN WIRE
BRN/GRN WIRE
BRN/VIO WIRE
COUPLING POINT ON ROOF
DOOR CONTACT SWITCH
DRIVER VANITY MIRROR LAMP
DRIVER VANITY MIRROR LAMP CONTACT SWITCH
FRONT PASSENGER DOOR WARNING LAMP
FRONT PASSENGER INTERIOR LOCKING BUTTON
FRONT PASSENGER VANITY MIRROR LAMP
FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH
GRN/YEL WIRE
GRY/RED WIRE
LEFT REAR INTERIOR LAMP
LEFT REAR READING LAMP
LEFT REAR READING LAMP SWITCH
LEFT THIRD ROW READING LAMP
LEFT THIRD ROW READING LAMP BUTTON
PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP
REAR INTERIOR LAMP
RED/BLU WIRE
RIGHT REAR DOOR COUPLING POINT
RIGHT REAR DOOR LOCK UNIT
RIGHT REAR INTERIOR LAMP
RIGHT REAR READING LAMP
RIGHT REAR READING LAMP SWITCH
RIGHT THIRD ROW READING LAMP
RIGHT THIRD ROW READING LAMP BUTTON
VIO/RED WIRE
WHT WIRE
YEL/BLU WIRE
YEL/VIO WIRE
Go to component -> Courtesy lamps circuit (2 of 3) -> RIGHT THIRD ROW READING LAMP BUTTON
