Volkswagen Teramont I (2017-2021) multi-function indicator Wiring diagram
This page shows the only wiring diagram for the component.multi-function indicator, which is found in the car Volkswagen Teramont I (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram multi-function indicator (1 of 1)
ABS INDICATOR LAMP
ANTI-THEFT SYSTEM
ASR/ ESP INDICATOR LAMP
BLU WIRE
BRAKE PAD WEAR INDICATOR LAMP
BRAKE SYSTEM INDICATOR LAMP
BRN WIRE
BRN/BLU WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
DIGITAL SOUND SYSTEM CONTROL MODULE
DRIVER DOOR CONTACT SWITCH
DRIVER DOOR CONTROL MODULE
DRIVER DOOR LOCK UNIT
ELECTRIC PARKING BRAKE MALFUNCTION INDICATOR LAMP
FRONT PASSENGER DOOR CONTACT SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER DOOR LOCK UNIT
FUEL DELIVERY UNIT (UNDER RIGHT REAR SEAT, IN FUEL TANK)
FUEL LEVEL SENSOR
FUSE 17
FUSE PANEL C
GRN WIRE
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
MULTI-FUNCTION INDICATOR
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
PARKING BRAKE INDICATOR LAMP
REAR FOG LAMP INDICATOR LAMP
RED/GRY WIRE
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
VIO/BLK WIRE
VIO/WHT WIRE
W/ AMPLIFIER
W/O AMPLIFIER
WHT/YEL WIRE
Go to component -> Instrument cluster circuit (1 of 2) -> MULTI-FUNCTION INDICATOR
