Volkswagen Taos I (2020-2024) Ground distribution circuit

ABS CONTROL MODULE ALL- WHEEL DRIVE CONTROL MODULE AM FREQUENCY FILTER BATTERY BATTERY MONITORING CONTROL MODULE BLK WIRE BRN WIRE DIGITAL SOUND SYSTEM CONTROL MODULE ENGINE/MOTOR CONTROL MODULE GRY WIRE HIGH-MOUNTED BRAKE LAMP LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT COUPLING POINT IN LUGGAGE COMPARTMENT LEFT COUPLING POINT ON REAR LID LEFT LICENSE PLATE LAMP LEFT TAIL LAMP LEFT TAIL LAMP 2 NCA WIRE POWER STEERING CONTROL MODULE REAR LID HANDLE REAR LID LOCK UNIT REAR WINDOW WIPER MOTOR RIGHT LICENSE PLATE LAMP RIGHT TAIL LAMP 2 SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE SECONDARY AIR INJECTION PUMP MOTOR WHT WIRE

A/C CLUTCH RELAY BRN WIRE COUPLING POINT IN LEFT FRONT DOOR COUPLING STATION IN LEFT FRONT SEAT DATA BUS ON BOARD DIAGNOSTIC INTERFACE DIAGNOSTIC CONNECTION DRIVER ASSISTANCE SYSTEMS FRONT CAMERA DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER EXTERIOR DOOR HANDLE DRIVER SEAT LUMBAR SUPPORT ADJUSTMENT SWITCH DRIVER SIDE DOOR AMBIENT LIGHTING LAMP DRIVER SIDE REAR WINDOW REGULATOR MOTOR DRIVER VANITY MIRROR LAMP CONTACT SWITCH FRONT INTERIOR LAMP INSTRUMENT CLUSTER INTERIOR REAR VIEW MIRROR LEFT FRONT DOOR COUPLING POINT LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT LEFT FRONT SEAT ADJUSTMENT CONTROL HEAD LEFT FRONT SEAT BACKREST FAN 1 LEFT FRONT SEAT COUPLING STATION LEFT FRONT SEAT CUSHION FAN 1 LEFT FRONT SEAT HEATER LEFT REAR DOOR COUPLING POINT LEFT REAR INTERIOR LAMP PARKING AID CONTROL MODULE RAIN/LIGHT RECOGNITION SENSOR REAR INTERIOR LAMP ROTARY LIGHT SWITCH SOCKETS RELAY STEERING COLUMN ELECTRONICS CONTROL MODULE TERMINAL 15 POWER SUPPLY RELAY VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ AMBIENT LIGHTING WHT WIRE

A/C COMPRESSOR REGULATOR VALVE ADAPTIVE CRUISE CONTROL MODULE BLK WIRE BRAKE FLUID LEVEL WARNING SWITCH BRAKE LAMP SWITCH BRN WIRE BRN/GRN WIRE BRN/WHT WIRE CHARGE AIR COOLING PUMP CORNERING LAMP, HEADLAMP RANGE CONTROL MODULE DUAL-CLUTCH TRANSMISSION MECHATRONIC IGNITION COIL 1 W/ POWER OUTPUT STAGE IGNITION COIL 2 W/ POWER OUTPUT STAGE IGNITION COIL 3 W/ POWER OUTPUT STAGE IGNITION COIL 4 W/ POWER OUTPUT STAGE LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT LEFT FRONT HEADLAMP LEFT FRONT RADIATOR GRILLE FIBER OPTIC CABLE CONTOUR ILLUMINATION LEFT HORN LEFT WASHER NOZZLE HEATER OIL LEVEL THERMAL SENSOR OIL SEPARATION FOR ACTIVE CONTROL UNIT RELAY & FUSE PANEL 3 WIPER MOTOR RELAY 1 RIGHT FRONT RADIATOR GRILLE FIBER OPTIC CABLE CONTOUR ILLUMINATION RIGHT WASHER NOZZLE HEATER TRANSMISSION CONTROL MODULE TRANSMISSION FLUID AUXILIARY HYDRAULIC PUMP 1 TRANSMISSION FLUID COOLER COUPLING POINT WIPER MOTOR CONTROL MODULE

BRN WIRE CAN BUS SUNROOF COUPLING POINT COUPLING POINT IN RIGHT FRONT DOOR COUPLING STATION IN RIGHT FRONT SEAT FRESH AIR BLOWER CONTROL MODULE FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER EXTERIOR DOOR HANDLE FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH LEFT FRONT SEAT BACKREST FAN 1 PASSENGER SIDE DOOR AMBIENT LIGHTING LAMP PASSENGER SIDE REAR WINDOW REGULATOR MOTOR RIGHT FRONT DOOR COUPLING POINT RIGHT FRONT EXTERIOR DOOR HANDLE COUPLING POINT RIGHT FRONT SEAT BACKREST FAN 1 RIGHT FRONT SEAT COUPLING STATION RIGHT FRONT SEAT CUSHION FAN 1 RIGHT FRONT SEAT HEATER RIGHT REAR DOOR COUPLING POINT RIGHT REAR INTERIOR LAMP SEAT OCCUPANT DETECTION SYSTEM CONTROL MODULE SUNROOF CONTROL MODULE W/ AMBIENT LIGHTING W/ SEAT VENTILATION W/ SUNROOF WHT WIRE

ACCESS/ START SYSTEM INTERFACE BLIND SPOT DETECTION CONTROL MODULE BLIND SPOT DETECTION CONTROL MODULE 2 BRN WIRE CENTER CONSOLE SWITCH MODULE 1 CENTER CONSOLE SWITCH MODULE 2 DRIVER EXTERIOR REAR VIEW MIRROR EARLY PRODUCTION EMERGENCY FLASHER SWITCH FRONT PASSENGER EXTERIOR REAR VIEW MIRROR FUEL FILLER DOOR UNLOCK FUEL PUMP CONTROL MODULE HEATER, A/C CONTROLS INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 1 INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 2 INSTRUMENT PANEL CONTOUR ILLUMINATION LAMP 3 LATE PRODUCTION LEFT FRONT DOOR COUPLING POINT PARKING BRAKE BUTTON REAR LID HANDLE REMOTE START SYSTEM RELAY RIGHT FRONT DOOR COUPLING POINT RIGHT TAIL LAMP SELECTOR MECHANISM START SYSTEM BUTTON USB CHARGING SOCKET 1 WHT WIRE

BLK WIRE BRN WIRE CELLULAR TELEPHONE PREPARATION CONTROL HEAD EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE ENGINE HOOD CONTACT SWITCH FRONT INFORMATION DISPLAY CONTROL HEAD HIGH TONE HORN INFORMATION ELECTRONICS CONTROL MODULE 1 LOW TONE HORN REAR LID HANDLE REFRIGERANT CIRCUIT PRESSURE SENSOR RELAY & FUSE PANEL 5 AUXILIARY HEATER RELAY RIGHT FRONT BRAKE PAD WEAR SENSOR RIGHT FRONT HEADLAMP STORAGE COMPARTMENT W/ CELL PHONE INTERFACE USB CONNECTION 1 W/ REAR VIEW CAMERA SYSTEM YEL WIRE
