Volkswagen Routan I (2008-2012) radio ctrl mux rtn lin bus Wiring diagram
This page shows the only wiring diagram for the component.radio ctrl mux rtn lin bus, which is found in the car Volkswagen Routan I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram radio ctrl mux rtn lin bus (1 of 1)
1 2 RADIO CTRL MUX
19 13 LIN BUS RADIO CTRL MUX RTN
4 3 2 EVIC/NAV MUX RTN SW ILLUM DRV EVIC MUX SIG 1
CLUSTER
COMPUTER DATA LINES SYSTEM
COMPUTER DATA LINKS SYSTEM
DK GRN/DK BLU WIRE
DK GRN/LT BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
EXCEPT EVIC
FUSED B (+)
GROUND
GRY/BLK WIRE
GRY/BLU WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/RED WIRE
GRY/WHT WIRE
GRY/YEL WIRE
HORNS SYSTEM
I/R AUDIO LEFT
I/R AUDIO RIGHT
I/R DIG AUDIO REF
I/R DIG AUDIO SIG 1
I/R DIG AUDIO SIG 2
LEFT D PILLAR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LEFT REMOTE RADIO SWITCH
LEFT STEERING WHEEL SWITCH
NCA WIRE
ORG/YEL WIRE
RADIO CTRL MUX
RADIO CTRL MUX RTN
RADIO CTRL MUX RTN LIN BUS
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REMOTE RADIO SWITCH
RIGHT STEERING WHEEL SWITCH
STEERING CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VDO-AUDIO LEFT 5
VDO-AUDIO RIGHT 5
VDO-AUDIO RTN 5
VDO-VIDEO COM 3
VDO-VIDEO SHIELD 3
VDO-VIDEO SHIELD 5
VDO-VIDEO SIG 3
VDO-VIDEO SIG 5
VIDEO SCREEN 1 MODULE
VIDEO SCREEN 3 MODULE
VIO WIRE
VIO/ORG WIRE
W/ SUNROOF
WHT/DK GRN WIRE
YEL/RED WIRE
Go to component -> Radio circuit, premium with dual dvd (3 of 4) -> RADIO CTRL MUX RTN LIN BUS
