Volkswagen Routan I (2008-2012) drv door sw lock sw mux return Wiring diagram

1 2 CAN BUS(-) CAN BUS(+) 1 4 5 6 2 GND FUSED B (+) FUSED B (+) REAR VENT WIND CLOSE REAR VENT WIND OPEN 14 12 1 8 RF MASTER WIND SW (DN) RF MASTER WIND SW (UP) FUSED B(+) FUSED B(+) 4 3 9 6 DOOR LOCK SW MUX DOOR LOCK SW MUX FUSED B(+) DRIVER FRONT DOOR LIN B(+) BLK WIRE BREAKOUT) DOOR LOCKS SYSTEM CIRCUIT BREAKER 1 COMPUTER DATA LINES SYSTEM DK BLU/PNK WIRE DK GRN/RED WIRE DRIVER DOOR MODULE (DRIVER FRONT DOOR) DRIVER FRONT DOOR LIN DRIVER RIGHT REAR WINDOW MOTOR VENT MOTOR (LEFT (RIGHT "D" PILLAR) FRONT DOOR) DRIVER WINDOW/DOOR LOCK SWITCH DRV DOOR SW LOCK SW MUX RETURN ELECTRONICS EXCEPT REAR WINDOW VENT FRONT PASSENGER WINDOW MOTOR (FRONT PASSENGER'S DOOR) FUSE HOT AT ALL TIMES LEFT REAR POWER WINDOW SWITCH (MEMORY W/O POWER SLIDING DOORS) LEFT REAR VENT MOTOR (LEFT "D" PILLAR) LEFT REAR WINDOW MOTOR (LEFT REAR DOOR) LT GRN/LT BLU WIRE LT GRN/TAN WIRE ORG/BRN WIRE ORG/DK BLU WIRE ORG/GRY WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/TAN WIRE ORG/VIO WIRE ORG/WHT WIRE PASSENGER WINDOW/DOOR LOCK SWITCH PNK/YEL WIRE REAR WINDOW VENT REAR WINDOW VENT SWITCH RIGHT DOOR LOCK SW MUX RIGHT REAR POWER WINDOW SWITCH (MEMORY W/O POWER SLIDING DOORS) RIGHT REAR WINDOW MOTOR (RIGHT REAR DOOR) RUN/ ACCESSORY RELAY RUN/ ACCESSORY RELAY CTRL TAN/LT BLU WIRE TAN/YEL WIRE TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) VIO/DK GRN WIRE VIO/LT GRN WIRE WHT/GRY WIRE WHT/ORG WIRE
