Volkswagen Routan I (2008-2012) camera return camera sig camera shield gnd backup lamp sw out Wiring diagram
This page shows the only wiring diagram for the component.camera return camera sig camera shield gnd backup lamp sw out, which is found in the car Volkswagen Routan I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram camera return camera sig camera shield gnd backup lamp sw out (1 of 1)
4 3 5 CAMERA RETURN CAMERA SIG CAMERA SHIELD
B(+)
BLK WIRE
BLK/DK GRN WIRE
CAMERA RETURN CAMERA SIG CAMERA SHIELD GND BACKUP LAMP SW OUT
ELECTRONICS PARK LAMP CTRL OUT
FUSE
GRY/LT BLU WIRE
GRY/ORG WIRE
HOT AT ALL TIMES
LICENSE PLATE LAMP/ REAR CAMERA ASSEMBLY (REAR CAMERA: LEFT SIDE OF LIFTGATE)
LT BLU WIRE
NCA WIRE
RADIO
TAN WIRE
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
Go to component -> Rear camera circuit -> CAMERA RETURN CAMERA SIG CAMERA SHIELD GND BACKUP LAMP SW OUT
