Volkswagen Routan I (2008-2012) backup lamp sw out Wiring diagram
This page shows the only wiring diagram for the component.backup lamp sw out, which is found in the car Volkswagen Routan I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram backup lamp sw out (1 of 1)
AUTO DAY/ NIGHT MIRR (+)
AUTO DAY/NIGHT MIRR (-)
BACKUP LAMP RELAY
BACKUP LAMP SW OUT
BLK WIRE
BLK/YEL WIRE
CAN INTR BUS (+)
COMPUTER DATA LINES SYSTEM
DK GRN/LT BLU WIRE
DK GRN/YEL WIRE
DRIVER DOOR MODULE (IN DRIVER DOOR)
EXCEPT BASE
FUSE
FUSED IGN SW OUT
HANDS FREE MODULE (BEHIND LEFT END OF DASH)
HOT W/ RUN/ START RELAY ENERGIZED
INSIDE REARVIEW MIRROR
LT BLU/WHT WIRE
LT GRN/DK BLU WIRE
LT GRN/DK GRN WIRE
MICROPHONE 1 IN (+)
MICROPHONE 2 IN (+)
MICROPHONE FEED
MICROPHONE IN (-)
NIGHT MIRR (-) AUTO DAY/
ORG/GRY WIRE
PNK/LT GRN WIRE
RADIO
SENS GND
SENSOR GROUND
TAN/ORG WIRE
TAN/WHT WIRE
TOTALLY INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT)
W/ NAVIGATION
W/ RAIN SENSE
W/O NAVIGATION
WHT/GRY WIRE
WHT/LT GRN WIRE
WHT/ORG WIRE
Go to component -> Automatic day/night mirror circuit, with hands free -> BACKUP LAMP SW OUT
