Volkswagen Routan I (2008-2012) aux video sig 2 aux video com 2 aux audio shld 2 Wiring diagrams
This page contains all the electrical diagrams for the component. aux video sig 2 aux video com 2 aux audio shld 2, in which he is found in the car Volkswagen Routan I (2008-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram aux video sig 2 aux video com 2 aux audio shld 2 (1 of 2)
1 2 3 4 5 6 7 8 AUX AUDIO LH SIG 1 AUX AUDIO RH SIG 1 AUX AUDIO COM 1
1 2 3 4 5 6 7 8 AUX AUDIO LH SIG 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
1/+
2/-
AMP LR SPKR (-) AMP RR SPKR (-)
AUX VIDEO SIG 1 AUX VIDEO COM 1 AUX AUDIO SHLD 1
AUX VIDEO SIG 2 AUX VIDEO COM 2 AUX AUDIO SHLD 2
AUXILIARY AUDIO VIDEO PORT 1
AUXILIARY AUDIO VIDEO PORT 2
BLK WIRE
CENTER INSTRUMENT PANEL SPEAKER
COMPUTER DATA LINES SYSTEM
DK BLU/YEL WIRE
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/LT BLU WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT REAR SPEAKER
NCA WIRE
RADIO AMPLIFIER (BEHIND LEFT QUARTERPANEL)
RIGHT D PILLAR SPEAKER
RIGHT FRONT LEFT FRONT DOOR DOOR SPEAKER SPEAKER
RIGHT REAR SPEAKER
SUBWOOFER
SUBWOOFER SPEAKER
VIDEO SCREEN 1 MODULE
WHT/GRY WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Radio circuit, premium with dual dvd (4 of 4) -> AUX VIDEO SIG 2 AUX VIDEO COM 2 AUX AUDIO SHLD 2
Wiring diagram aux video sig 2 aux video com 2 aux audio shld 2 (2 of 2)
1 2 3 4 5 6 7 8 AUX AUDIO LH SIG 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
1/+
2/-
AMP LR SPKR (-) AMP RR SPKR (-)
AUX VIDEO COM 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
AUX VIDEO SIG 2 AUX VIDEO COM 2 AUX AUDIO SHLD 2
AUX VIDEO SIG 2 AUX VIDEO SHLD 2 AUX AUDIO LH SIG 2
AUXILIARY AUDIO VIDEO PORT 2
BLK WIRE
CENTER INSTRUMENT PANEL SPEAKER
COMPUTER DATA LINES SYSTEM
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT D PILLAR SPEAKER
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LEFT REAR SPEAKER
NCA WIRE
RADIO AMPLIFIER (BEHIND LEFT QUARTERPANEL)
RIGHT D PILLAR SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR SPEAKER
SUBWOOFER
SUBWOOFER SPEAKER
VIDEO SCREEN 2 MODULE
WHT/GRY WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Radio circuit, premium without dual dvd (3 of 3) -> AUX VIDEO SIG 2 AUX VIDEO COM 2 AUX AUDIO SHLD 2
