Volkswagen Routan I (2008-2012) aux video com 2 aux audio rh sig 2 aux audio com 2 Wiring diagram
This page shows the only wiring diagram for the component.aux video com 2 aux audio rh sig 2 aux audio com 2, which is found in the car Volkswagen Routan I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram aux video com 2 aux audio rh sig 2 aux audio com 2 (1 of 1)
1 2 3 4 5 6 7 8 AUX AUDIO LH SIG 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
1/+
2/-
AMP LR SPKR (-) AMP RR SPKR (-)
AUX VIDEO COM 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
AUX VIDEO SIG 2 AUX VIDEO COM 2 AUX AUDIO SHLD 2
AUX VIDEO SIG 2 AUX VIDEO SHLD 2 AUX AUDIO LH SIG 2
AUXILIARY AUDIO VIDEO PORT 2
BLK WIRE
CENTER INSTRUMENT PANEL SPEAKER
COMPUTER DATA LINES SYSTEM
DK GRN/BRN WIRE
DK GRN/DK BLU WIRE
DK GRN/GRY WIRE
DK GRN/ORG WIRE
DK GRN/TAN WIRE
DK GRN/VIO WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
GRY/BRN WIRE
GRY/DK BLU WIRE
GRY/DK GRN WIRE
GRY/LT BLU WIRE
GRY/LT GRN WIRE
GRY/ORG WIRE
GRY/TAN WIRE
GRY/VIO WIRE
GRY/WHT WIRE
GRY/YEL WIRE
LEFT D PILLAR SPEAKER
LEFT FRONT DOOR SPEAKER
LEFT INSTRUMENT PANEL SPEAKER
LEFT REAR SPEAKER
NCA WIRE
RADIO AMPLIFIER (BEHIND LEFT QUARTERPANEL)
RIGHT D PILLAR SPEAKER
RIGHT FRONT DOOR SPEAKER
RIGHT INSTRUMENT PANEL SPEAKER
RIGHT REAR SPEAKER
SUBWOOFER
SUBWOOFER SPEAKER
VIDEO SCREEN 2 MODULE
WHT/GRY WIRE
WHT/ORG WIRE
YEL/GRY WIRE
YEL/RED WIRE
Go to component -> Radio circuit, premium without dual dvd (3 of 3) -> AUX VIDEO COM 2 AUX AUDIO RH SIG 2 AUX AUDIO COM 2
