Volkswagen Routan I (2008-2012) 26 27 23 14 downshift sig upshift sig brk sig 1 brk sig 2 Wiring diagram
This page shows the only wiring diagram for the component.26 27 23 14 downshift sig upshift sig brk sig 1 brk sig 2, which is found in the car Volkswagen Routan I (2008-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 26 27 23 14 downshift sig upshift sig brk sig 1 brk sig 2 (1 of 1)
12 7 TRS PARK SIG BRAKE TRANS SHIFT
2 6 4 5 B(+) BRAKE SIG 1 BRAKE SIG 2 GROUND
26 27 23 14 DOWNSHIFT SIG UPSHIFT SIG BRK SIG 1 BRK SIG 2
3 4 5 SENS GND TRANS TEMP SIG
35 27 15 16 37 TRANS TEMP SIG
35 34 CAN C BUS (-) CAN C BUS (+)
BLK WIRE
BLK/YEL WIRE
BRN/YEL WIRE
CAN C (+)
COMPUTER DATA LINES SYSTEM
DK BLU/DK GRN WIRE
DK GRN/DK BLU WIRE
DK GRN/PNK WIRE
DK GRN/WHT WIRE
DK GRN/YEL WIRE
ELECTRONICS
FUSE
HOT AT ALL TIMES
HOT W/ RUN/START RELAY ENERGIZED
LT BLU/DK GRN WIRE
LT GRN/RED WIRE
PNK/LT GRN WIRE
POWERTRAIN CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
SHIFTER LEVER ASSEMBLY (BEHIND LEFT CENTER OF DASH)
STOP LAMP SWITCH (TOP OF BRAKE PEDAL)
TRANSMISSION RANGE SENSOR (3.3L/3.8L/4 SPEED)
WHT/BLK WIRE
WHT/BRN WIRE
WHT/LT BLU WIRE
WIRELESS IGNITION NODE
YEL/DK BLU WIRE
YEL/DK GRN WIRE
Go to component -> Shift interlock circuit -> 26 27 23 14 DOWNSHIFT SIG UPSHIFT SIG BRK SIG 1 BRK SIG 2
