Volkswagen Routan I (2008-2012) 1 2 3 4 5 6 7 8 9 10 11 12 pos sens sig 1 optical sens sply Wiring diagram

1 2 3 4 5 6 7 8 9 10 11 12 POS SENS SIG 1 OPTICAL SENS SPLY 1 2 GROUND FUSED B (+) 6 5 4 7 POS SNS LOGIC GND CINCH DRV AJAR SW SNS AJAR BANK 2 SWITCH BLK/LT GRN WIRE BLK/ORG WIRE BLK/YEL WIRE BUS - CAN INT CAN INT BUS (-) (+) CAN INT BUS (-) CAN INT BUS (+) CHIME DRV SECOND POS SNS AJAR SW SNS CINCH DRV CHIME COMPUTER DATA LINES SYSTEM DRV (+) FUSE HOT AT ALL TIMES LEFT LIFTGATE PINCH SENSOR (LEFT SIDE OF LIFTGATE) LIFTGATE CLTCH DRV OPEN DRV CLOSE DRV POS SENS SIG 2 LIFTGATE DOOR LATCH (LOWER CENTER OF LIFTGATE) LOGIC GND SW SNS SW SNS OPEN SW SNS ORG/ WIRE ORG/BRN WIRE ORG/DK BLU WIRE ORG/DK GRN WIRE ORG/LT BLU WIRE ORG/LT GRN WIRE ORG/TAN WIRE ORG/VIO WIRE POWER LIFTGATE CHIME (BASE OF LEFT "D" PILLAR) POWER LIFTGATE DRIVE UNIT (LEFT "D" PILLAR) POWER LIFTGATE MODULE (MOUNTED ON LEFT "D" PILLAR) POWER LIFTGATE SWITCH (LEFT "D" PILLAR) RELEASE DRV RIGHT LIFTGATE PINCH SENSOR (RIGHT SIDE OF LIFTGATE) SECTOR SW SNS SW SIG PINCH SENS SIG SECTOR SW SNS PINCH SENS SIG SW SNS TAN/BRN WIRE TAN/DK GRN WIRE TAN/GRY WIRE TAN/LT GRN WIRE TAN/ORG WIRE TAN/WHT WIRE TOTALLY ELECTRONICS INTEGRATED POWER MODULE (LEFT SIDE OF ENGINE COMPT) VIO WIRE VIO/TAN WIRE WHT WIRE WHT/GRY WIRE WHT/ORG WIRE YEL/RED WIRE
