Charging circuit for Volkswagen Passat B8 facelift (2019-2024)
Charging circuit
BATTERY
BLK WIRE
COMPUTER DATA LINES SYSTEM
DATA BUS ON BOARD DIAGNOSTIC INTERFACE
FUSE 1
FUSE PANEL A
GENERATOR INDICATOR LAMP
GENERATOR W/ VOLTAGE REGULATOR
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
NCA WIRE
ORG/BLU WIRE
ORG/BRN WIRE
STARTER
VIO/WHT WIRE
