Horn circuit for Volkswagen Passat B8 facelift (2019-2024)
Horn circuit
AIR BAG SPIRAL SPRING/ RETURN SPRING (W/ SLIP RING)
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU/WHT WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 35
FUSE 36
FUSE 43
FUSE PANEL C
GRY WIRE
HORN RELAY
HOT AT ALL TIMES
LEFT COUPLING POINT IN ENGINE/MOTOR COMPARTMENT
LEFT HORN
MULTI-FUNCTION STEERING WHEEL CONTROL MODULE
ORG/BRN WIRE
ORG/GRN WIRE
RED/BRN WIRE
RED/WHT WIRE
RED/YEL WIRE
SIGNAL HORN ACTIVATION
STEERING COLUMN ELECTRONICS CONTROL MODULE
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO/WHT WIRE
W/ ADAPTIVE CRUISE CONTROL
W/O ADAPTIVE CRUISE CONTROL
