Volkswagen Passat B8 facelift (2019-2024) w/o remote start function Wiring diagram
This page shows the only wiring diagram for the component.w/o remote start function, which is found in the car Volkswagen Passat B8 facelift (2019-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram w/o remote start function (1 of 1)
ACCESS/START AUTHORIZATION CONTROL MODULE
ANTENNA
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR, ACCESS/START SYSTEM ANTENNA
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
ENGINE CONTROLS SYSTEM
FRONT PASSENGER EXTERIOR DOOR HANDLE TOUCH SENSOR, ACCESS/START SYSTEM ANTENNA
FUSE 1
FUSE 24
FUSE PANEL C
GRN WIRE
GRN/BLU WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LEFT FRONT DOOR COUPLING POINT
LEFT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
LUGGAGE COMPARTMENT ACCESS/START SYSTEM ANTENNA
ORG/BRN WIRE
ORG/GRN WIRE
POWER REAR LID OPENING CONTROL MODULE
REAR BUMPER ACCESS/START SYSTEM ANTENNA
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RIGHT FRONT DOOR COUPLING POINT
RIGHT FRONT EXTERIOR DOOR HANDLE COUPLING POINT
RIGHT LUGGAGE COMPT COUPLING POINT
SELECTOR LEVER (A/T)
START SYSTEM BUTTON
STEERING COLUMN LOCK ACTUATOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 1
VEHICLE INTERIOR ACCESS/START SYSTEM ANTENNA 2
VIO WIRE
VIO/BLK WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ REMOTE START FUNCTION
W/O REMOTE START FUNCTION
WHT WIRE
WHT/BLU WIRE
Go to component -> Access/start circuit -> W/O REMOTE START FUNCTION
