Tire pressure monitoring circuit for Volkswagen Passat B8 (2014-2020)
Tire pressure monitoring circuit
ABS CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
FUSE 13
FUSE PANEL C
GRY WIRE
HOT W/ TERMINAL 15 RELAY ENERGIZED
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER CONTROL MODULE
ORG/BLK WIRE
ORG/BLU WIRE
ORG/BRN WIRE
PUSH BUTTON ILLUMINATION BULB
TIRE PRESSURE MONITORING DISPLAY BUTTON
TIRE PRESSURE MONITORING DISPLAY INDICATOR LAMP
