Supplemental restraints circuit for Volkswagen Passat B8 (2014-2020)

Supplemental restraints circuit (1 of 3)

Passat Volkswagen B8 (2014-2020): Supplemental restraints circuit (1 of 3)

Get access

AIR BAG CONTROL MODULE BLK WIRE BLK/RED WIRE BLU WIRE BLU/YEL WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER HEAD CURTAIN AIR BAG IGNITER DRIVER SEAT BELT TENSIONER IGNITER 2 FRONT PASSENGER AIR BAG DISABLED INDICATOR LAMP FRONT PASSENGER AIR BAG UNIT FRONT PASSENGER HEAD CURTAIN AIR BAG IGNITER FRONT PASSENGER SEAT BELT TENSIONER IGNITER 2 FUSE 3 FUSE 9 FUSE PANEL C GRN WIRE GRN/RED WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED IGNITER 1 IGNITER 2 RED WIRE RED/YEL WIRE WHT WIRE YEL WIRE YEL/BLK WIRE YEL/GRY WIRE

Supplemental restraints circuit (2 of 3)

Passat Volkswagen B8 (2014-2020): Supplemental restraints circuit (2 of 3)

Get access

AIR BAG INDICATOR LAMP BLK/RED WIRE BRN WIRE BRN/BLK WIRE COMPUTER DATA LINES SYSTEM DRIVER SEAT BELT SWITCH DRIVER THORAX AIR BAG IGNITER FRONT PASSENGER SEAT BELT SWITCH FRONT PASSENGER SEAT HEATING ELEMENT W/ SEAT OCCUPANT DETECTION CONTROL MODULE FRONT PASSENGER THORAX AIR BAG IGNITER FRONT SEAT HEATING CONTROL MODULE GRN WIRE GRN/RED WIRE GRN/YEL WIRE GROUND DISTRIBUTION SYSTEM INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE ORG/BLU WIRE ORG/BRN WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE RED/WHT WIRE RED/YEL WIRE SEAT BELT INDICATOR LAMP SEATS SYSTEM VIO/BLK WIRE VIO/BLU WIRE WHT WIRE YEL/GRY WIRE

Supplemental restraints circuit (3 of 3)

Passat Volkswagen B8 (2014-2020): Supplemental restraints circuit (3 of 3)

Get access

AIR BAG CONTROL MODULE AIR BAG SPIRAL SPRING/RETURN SPRING W/ SLIP RING BATTERY BLK WIRE BLK/RED WIRE BLU WIRE BLU/RED WIRE BRN WIRE COMPUTER DATA LINES SYSTEM DRIVER AIR BAG IGNITER DRIVER FRONT AIR BAG CRASH SENSOR DRIVER SEAT BELT TENSIONER IGNITER 1 DRIVER SIDE REAR THORAX AIR BAG CRASH SENSOR DRIVER THORAX AIR BAG CRASH SENSOR FRONT PASSENGER SEAT BELT TENSIONER IGNITER 1 FRONT PASSENGER THORAX AIR BAG CRASH SENSOR GRN WIRE GRY WIRE GRY/RED WIRE ORG/BLK WIRE ORG/BRN WIRE PASSENGER SIDE FRONT AIR BAG CRASH SENSOR PASSENGER SIDE REAR THORAX AIR BAG CRASH SENSOR RED WIRE STARTING/ CHARGING SYSTEM STEERING COLUMN ELECTRONICS CONTROL MODULE VIO WIRE VIO/BLK WIRE YEL WIRE YEL/GRY WIRE
