Passenger power seat circuit for Volkswagen Passat B8 (2014-2020)
Passenger power seat circuit
BACKREST ADJUSTMENT BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER, FRONT PASSENGER SEAT CIRCUIT BREAKER
FORWARD/BACK ADJUSTMENT BUTTON
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBER SUPPORT ADJUSTMENT SWITCH
GRN WIRE
GRY WIRE
HEIGHT ADJUSTMENT BUTTON
HOT AT ALL TIMES
N/A
RED WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 2
RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD
YEL WIRE
