Power mirrors circuit for Volkswagen Passat B8 (2014-2020)
Power mirrors circuit
ADJUSTMENT MOTOR
ADJUSTMENT MOTOR 2
BLIND SPOT DETECTION WARNING LAMP
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DEFOGGER SYSTEM
DRIVER DOOR CONTROL MODULE
DRIVER EXTERIOR REAR VIEW MIRROR
EXTERIOR REAR VIEW MIRROR ADJUSTER
EXTERIOR REAR VIEW MIRROR HEATING SWITCH
FRONT PASSENGER DOOR CONTROL MODULE
FRONT PASSENGER EXTERIOR REAR VIEW MIRROR
FUSE 45
FUSE 46
FUSE PANEL C
GRN WIRE
GRY WIRE
GRY/YEL WIRE
HEATER
HOT AT ALL TIMES
MIRROR ADJUSTING SWITCH
MIRROR ADJUSTMENT SWITCH ILLUMINATION BULB
MIRROR FOLDING SWITCH
MIRROR SELECTOR SWITCH
NAVIGATION SYSTEM
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
TURN
WHT WIRE
YEL WIRE
YEL/GRY WIRE
