Emergency call circuit for Volkswagen Passat B8 (2014-2020)
Emergency call circuit
BLK WIRE
BRN WIRE
BRN/YEL WIRE
COMPUTER DATA LINES SYSTEM
EMERGENCY CALL BUTTON
EMERGENCY CALL MODULE, COMMUNICATION UNIT CONTROL MODULE
FUSE 4
FUSE PANEL C
GPS ANTENNA
GRN/BLU WIRE
GRY WIRE
GRY/BLK WIRE
GSM ANTENNA/ TELEPHONE ANTENNA
HOT AT ALL TIMES
INFORMATION ELECTRONICS CONTROL MODULE 1
ORG/BRN WIRE
ORG/VIO WIRE
RED/BLU WIRE
RED/VIO WIRE
RED/WHT WIRE
ROOF ANTENNA
TELEPHONE MICROPHONE
WHT WIRE
WHT/BLU WIRE
