Courtesy lamps circuit for Volkswagen Passat B8 (2014-2020)

Courtesy lamps circuit (1 of 3)

Passat Volkswagen B8 (2014-2020): Courtesy lamps circuit (1 of 3)

Get access

AUTOMATIC DIMMING INTERIOR REAR VIEW MIRROR BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BRN WIRE BRN/BLU WIRE BRN/RED WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM FRONT INTERIOR LAMP FUSE 30 FUSE PANEL C GRY WIRE HOT W/ TERMINAL 75 POWER SUPPLY RELAY 1 ENERGIZED INSTRUMENT ILLUMINATION CIRCUIT LEFT CENTER READING LAMP LEFT FRONT FOOTWELL ILLUMINATION BULB LEFT REAR DOOR CONTACT SWITCH LEFT REAR DOOR LOCK UNIT LUGGAGE COMPARTMENT LAMP LUGGAGE COMPARTMENT LAMP SWITCH ORG/BRN WIRE ORG/GRN WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT CENTER READING LAMP RIGHT FRONT FOOTWELL ILLUMINATION BULB RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR DOOR LOCK UNIT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE WHT WIRE

Courtesy lamps circuit (2 of 3)

Passat Volkswagen B8 (2014-2020): Courtesy lamps circuit (2 of 3)

Get access

BRN WIRE BRN/VIO WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER DOOR CONTACT SWITCH DRIVER DOOR CONTROL MODULE DRIVER DOOR LOCK UNIT DRIVER DOOR WARNING LAMP FUSE 45 FUSE PANEL C GLOVE COMPARTMENT LAMP GLOVE COMPARTMENT LAMP SWITCH HOT AT ALL TIMES LEFT REAR READING LAMP ORG/BRN WIRE ORG/GRN WIRE REAR INTERIOR LAMP RED WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE RIGHT REAR READING LAMP

Courtesy lamps circuit (3 of 3)

Passat Volkswagen B8 (2014-2020): Courtesy lamps circuit (3 of 3)

Get access

BRN WIRE BRN/YEL WIRE COMPUTER DATA LINES SYSTEM DRIVER VANITY MIRROR LAMP DRIVER VANITY MIRROR LAMP CONTACT SWITCH FRONT PASSENGER DOOR CONTACT SWITCH FRONT PASSENGER DOOR CONTROL MODULE FRONT PASSENGER DOOR LOCK UNIT FRONT PASSENGER DOOR WARNING LAMP FRONT PASSENGER VANITY MIRROR LAMP FRONT PASSENGER VANITY MIRROR LAMP CONTACT SWITCH FUSE 46 FUSE PANEL C HOT AT ALL TIMES ORG/BRN WIRE ORG/GRN WIRE RED WIRE RED/BLK WIRE RED/BLU WIRE RED/WHT WIRE RED/YEL WIRE
