Car Wiring Diagrams for Cruise control circuit for Volkswagen Passat B8 (2014-2020)

3.6L 3.6L 1.8L TURBO BLK WIRE BLK/BLU WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/GRN WIRE BRN/GRY WIRE COMPUTER DATA LINES SYSTEM CRUISE CONTROL INDICATOR LAMP CRUISE CONTROL SWITCH, CRUISE CONTROL SET-BUTTON DISTANCE REGULATION CONTROL MODULE DRIVESHAFT SPEED SENSOR 1 DRIVESHAFT SPEED SENSOR 2 DSG TRANSMISSION MECHATRONIC ENGINE CONTROL MODULE EPC THROTTLE DRIVE EPC THROTTLE DRIVE ANGLE SENSOR 1 EPC THROTTLE DRIVE ANGLE SENSOR 2 FUSE 13 FUSE PANEL C GRN WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE HOT W/ TERMINAL 15 RELAY ENERGIZED INSTRUMENT CLUSTER INSTRUMENT CLUSTER CONTROL MODULE NCA WIRE ORG/BLK WIRE ORG/BLU WIRE ORG/BRN WIRE ORG/GRN WIRE RED/BLK WIRE RED/VIO WIRE STEERING COLUMN ELECTRONICS CONTROL MODULE THROTTLE VALVE CONTROL MODULE TRANSMISSION INPUT SPEED SENSOR, CLUTCH OIL TEMPERATURE SENSOR TRANSMISSION OUTPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR 2 WHT/BLU WIRE WHT/GRN WIRE WHT/YEL WIRE YEL/GRN WIRE

1.8L TURBO 1.8L TURBO 3.6L 3.6L ACCELERATOR PEDAL MODULE (ACCELERATOR PEDAL ASSEMBLY) ACCELERATOR PEDAL POSITION SENSOR ACCELERATOR PEDAL POSITION SENSOR 2 BLK WIRE BLK/GRY WIRE BLK/RED WIRE BRAKE LAMP SWITCH BRN WIRE BRN/BLU WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM ENGINE SPEED SENSOR FUSE 10 FUSE 14 FUSE 3 FUSE PANEL B FUSE PANEL F GRN WIRE GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/RED WIRE GRY/YEL WIRE HOT AT ALL TIMES MOTRONIC ENGINE CONTROL MODULE POWER SUPPLY RELAY ORG/BLK WIRE ORG/BRN WIRE RED WIRE RED/BLK WIRE RED/YEL WIRE TRANSMISSION TRANSMISSION CONTROL MODULE TRANSMISSION INPUT SPEED SENSOR TRANSMISSION OUTPUT SPEED SENSOR VIO WIRE WHT WIRE WHT/BLU WIRE WHT/BRN WIRE WHT/GRN WIRE WHT/RED WIRE WHT/YEL WIRE YEL/BRN WIRE YEL/GRN WIRE YEL/RED WIRE
