Volkswagen Passat B8 (2014-2020) vehicle interior access/start authorization antenna 2 Wiring diagram
This page shows the only wiring diagram for the component.vehicle interior access/start authorization antenna 2, which is found in the car Volkswagen Passat B8 (2014-2020). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram vehicle interior access/start authorization antenna 2 (1 of 1)
ACCESS/START AUTHORIZATION CONTROL MODULE
ANTENNA
BLK WIRE
BLK/BLU WIRE
BLK/YEL WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
DRIVER EXTERIOR DOOR HANDLE TOUCH SENSOR, ACCESS/START AUTHORIZATION ANTENNA
ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE
ENGINE CONTROLS SYSTEM
FUSE 1
FUSE 24
FUSE PANEL C
GRN WIRE
GRN/BLU WIRE
GRN/YEL WIRE
GRY WIRE
GRY/RED WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
LUGGAGE COMPARTMENT ACCESS/START AUTHORIZATION ANTENNA
NCA WIRE
ORG/BRN WIRE
ORG/GRN WIRE
REAR BUMPER ACCESS/START AUTHORIZATION ANTENNA
REAR LID OPENER CONTROL MODULE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
REMOTE START SYSTEM RELAY (RELAY & FUSE PANEL 2)
SELECTOR LEVER (A/T)
START SYSTEM BUTTON
STARTER RELAY 1 (W/O REMOTE START) (RELAY & FUSE PANEL 2)
STEERING COLUMN LOCK ACTUATOR
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VEHICLE INTERIOR ACCESS/START AUTHORIZATION ANTENNA 1
VEHICLE INTERIOR ACCESS/START AUTHORIZATION ANTENNA 2
VIO/BLK WIRE
VIO/RED WIRE
VIO/WHT WIRE
VIO/YEL WIRE
W/ REMOTE START FUNCTION W/O REMOTE START FUNCTION
WHT WIRE
WHT/BLU WIRE
WHT/YEL WIRE
Go to component -> Access/start circuit -> VEHICLE INTERIOR ACCESS/START AUTHORIZATION ANTENNA 2
