Volkswagen Passat B8 (2014-2020) forward/back adjustment button Wiring diagrams
This page contains all the electrical diagrams for the component. forward/back adjustment button, in which he is found in the car Volkswagen Passat B8 (2014-2020). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
forward/back adjustment button wiring diagram (1 of 2)
BACKREST ADJUSTMENT BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER BACKREST ADJUSTMENT MOTOR
DRIVER SEAT FORWARD/BACK ADJUSTMENT MOTOR
DRIVER SEAT HEIGHT ADJUSTMENT MOTOR
DRIVER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
DRIVER SEAT LUMBER SUPPORT ADJUSTMENT SWITCH
DRIVER, FRONT PASSENGER SEAT CIRCUIT BREAKER
FORWARD/BACK ADJUSTMENT BUTTON
GRN WIRE
GRY WIRE
HEIGHT ADJUSTMENT BUTTON
HOT AT ALL TIMES
LEFT FRONT SEAT ADJUSTMENT CONTROL HEAD
N/A
RED/BLK WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/GRY WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 2
Go to component -> Driver power seat circuit -> FORWARD/BACK ADJUSTMENT BUTTON
forward/back adjustment button wiring diagram (2 of 2)
BACKREST ADJUSTMENT BUTTON
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER, FRONT PASSENGER SEAT CIRCUIT BREAKER
FORWARD/BACK ADJUSTMENT BUTTON
FRONT PASSENGER BACKREST ADJUSTMENT MOTOR
FRONT PASSENGER SEAT FORWARD/BACK ADJUSTMENT MOTOR
FRONT PASSENGER SEAT HEIGHT ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBAR SUPPORT CURVATURE ADJUSTMENT MOTOR
FRONT PASSENGER SEAT LUMBER SUPPORT ADJUSTMENT SWITCH
GRN WIRE
GRY WIRE
HEIGHT ADJUSTMENT BUTTON
HOT AT ALL TIMES
N/A
RED WIRE
RED/YEL WIRE
RELAY & FUSE PANEL 2
RIGHT FRONT SEAT ADJUSTMENT CONTROL HEAD
YEL WIRE
Go to component -> Passenger power seat circuit -> FORWARD/BACK ADJUSTMENT BUTTON
