Car Wiring Diagrams for Power mirrors circuit for Volkswagen Passat B7 (2010-2015)

ADJUSTMENT MOTORS BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLU/RED WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DEFOGGER SYSTEM DRIVER'S EXTERIOR REAR VIEW MIRROR DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR) EXTERIOR REAR VIEW MIRROR HEATING SWITCH FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR) FRONT PASSENGER'S OUTSIDE MIRROR FUSE 22 FUSE 31 FUSE PANEL GRY WIRE GRY/WHT WIRE GRY/YEL WIRE HEATER HORIZONTAL POSITION SENSOR (IF EQUIPPED) HOT AT ALL TIMES MIRROR ADJUSTMENT ILLUMINATION BULB MIRROR FOLDING SWITCH MIRROR SELECTOR SWITCH ORG/BRN WIRE ORG/GRN WIRE OUTSIDE MIRROR SWITCH MIRROR ADJUSTMENT SWITCH RED WIRE RED/YEL WIRE TURN VERTICAL POSITION SENSOR (IF EQUIPPED) WHT WIRE WHT/YEL WIRE YEL WIRE
