Volkswagen Passat B7 (2010-2015) access/ data bus authorization on board control diagnostic module interface Wiring diagram

3.6L ACCESS/ DATA BUS AUTHORIZATION ON BOARD CONTROL DIAGNOSTIC MODULE INTERFACE BATTERY BLK WIRE BLU WIRE COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR DRIVER DOOR CONTROL MODULE DRIVER SEAT ADJUSTMENT CONTROL HEAD DRIVER SEAT ADJUSTMENT CONTROL MODULE DRIVER SIDE REAR DOOR CONTROL MODULE DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER (ABOVE RELAY CARRIER, UNDER LEFT ELECTRONIC STEERING COLUMN LOCK CONTROL MODULE END OF DASH) FUSE 35 EXCEPT 3.6L EXCEPT 3.6L 3.6L FRESH AIR BLOWER CONTROL MODULE (AUTOMATIC A/C) FROM FUSE PANEL B (DIAGRAM 3 OF 4) FROM FUSE PANEL C (DIAGRAM 1 OF 4) FROM FUSE PANEL F (DIAGRAM 4 OF 4) FROM POWER SUPPLY RELAY (TERMINAL 50) (DIAGRAM 4 OF 4) FROM SUPPRESSOR (DIAGRAM 4 OF 4) FRONT PASSENGER SEAT ADJUSTMENT CONTROL HEAD FRONT SEAT HEATING CONTROL MODULE FUSE FUSE 1 FUSE 12 FUSE 13 FUSE 16 FUSE 15 FUSE 17 FUSE 2 FUSE 29 FUSE 3 FUSE 30 FUSE 31 FUSE 32 FUSE 33 FUSE 34 FUSE PANEL A (IN ENGINE COMPT ELECTRONICS BOX) FUSE PANEL C (AT LEFT GENERATOR W/ VOLTAGE REGULATOR GRN WIRE IGNITION/STARTER SWITCH LIGHT SWITCH N/A NCA WIRE ORG/BRN WIRE ORG/GRN WIRE POWER STEERING CONTROL MODULE POWER SUNROOF CONTROL MODULE RED WIRE RED/BLK WIRE RED/YEL WIRE SIDE OF DASH) STARTER STEERING COLUMN ELECTRONICS CONTROL MODULE (ON STEERING COLUMN, TIPTRONIC SWITCH TO DRIVER'S POWER SEAT ADJUSTMENT CIRCUIT BREAKER (DIAGRAM 1 OF 4) TO FUSE 23 (DIAGRAM 3 OF 4) TO FUSE PANEL C (DIAGRAM 2 OF 4) TO FUSE PANEL F (DIAGRAM 4 OF 4) TO SUPPRESSOR (DIAGRAM 4 OF 4) VEHICLE ELECTRICAL SYSTEM CONTROL MODULE W/ PASSENGER'S POWER SEAT W/O PASSENGER'S POWER SEAT WHT WIRE YEL WIRE
