Courtesy lamps circuit for Volkswagen Passat B6 (2005-2010)

BLK WIRE BLK/BLU WIRE BLU WIRE BRN WIRE BRN/VIO WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM DRIVER'S DOOR CONTACT SWITCH DRIVER'S DOOR CONTROL MODULE (IN DRIVER'S DOOR) DRIVER'S ENTRY LAMP DRIVER'S OUTSIDE MIRROR FRONT INTERIOR LAMP FRONT PASSENGER'S DOOR CONTACT SWITCH FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR) FRONT PASSENGER'S ENTRY LAMP FRONT PASSENGER'S OUTSIDE MIRROR GLOVE COMPARTMENT LAMP SWITCH GLOVE COMPARTMENT LIGHT GRN WIRE GRN/BLU WIRE HOT AT ALL TIMES FUSE PANEL FUSE 29 LEFT CENTER READING LIGHT FRONT INTERIOR LIGHT LEFT FRONT ENTRY LIGHT ORG/BRN WIRE ORG/GRN WIRE PASSENGER COMPARTMENT MONITORING SWITCH RED WIRE RED/BLU WIRE RED/VIO WIRE RED/YEL WIRE RIGHT CENTER READING LIGHT RIGHT FRONT ENTRY LIGHT VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH) VIO WIRE VIO/BRN WIRE VIO/RED WIRE WHT WIRE

1 2 (SEDAN) (WAGON) 2 3 (SEDAN) (WAGON) BLK WIRE BLK/BLU WIRE BLK/GRN WIRE BLU WIRE BRN WIRE BRN/BLK WIRE BRN/VIO WIRE COMPUTER DATA LINES SYSTEM DRIVER'S MAKE-UP MIRROR LIGHT CONTACT SWITCH DRIVER`S ILLUMINATED MAKE-UP MIRROR LIGHT FRONT PASSENGER'S ILLUMINATED MAKE-UP MIRROR LIGHT FRONT PASSENGER'S MAKE-UP MIRROR LIGHT CONTACT SWITCH GRN WIRE GRN/BLU WIRE LEFT FOOTWELL LIGHT LEFT REAR DOOR CONTACT SWITCH LEFT REAR ENTRY LIGHT LEFT REAR READING LIGHT REAR COURTESY LIGHT LUGGAGE COMPARTMENT LIGHT LUGGAGE COMPARTMENT LIGHT SWITCH NCA WIRE ORG/BRN WIRE ORG/GRN WIRE REAR COURTESY LIGHT REAR LID LOCK UNIT (BOTTOM CENTER OF REAR LID DOOR) RED WIRE RED/BLU WIRE RIGHT FOOTWELL LIGHT RIGHT REAR DOOR CONTACT SWITCH RIGHT REAR ENTRY LIGHT RIGHT REAR READING LIGHT SEDAN SEDAN WAGON VIO WIRE VIO/BRN WIRE VIO/RED WIRE W/ REAR ELECTRIC WINDOW REGULATOR W/O REAR ELECTRIC WINDOW REGULATOR WAGON WHT WIRE YEL WIRE YEL/BLU WIRE
