Volkswagen Passat B6 (2005-2010) special purpose vehicle control module Wiring diagram
This page shows the only wiring diagram for the component.special purpose vehicle control module, which is found in the car Volkswagen Passat B6 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram special purpose vehicle control module (1 of 1)
A/C CONTROL MODULE
AUTOMATIC A/C
BLK WIRE
BLK/VIO WIRE
BLU/BLK WIRE
BLU/YEL WIRE
BRN WIRE
CLIMATRONIC CONTROL MODULE
DATA BUS ON BOARD DIAGNOSTIC INTERFACE (UNDER LEFT SIDE OF DASH)
DATA LINK CONNECTOR
DRIVER'S
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S DOOR)
FUSE 1 FUSE 7 FUSE 13 (AT LEFT END OF DASH)
FUSE 24 (LEFT SIDE OF ENGINE COMPT)
FUSE PANEL
GRY/WHT WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER CONTROL MODULE
MANUAL A/C
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
ORG/VIO WIRE
PARKING AID CONTROL MODULE (RIGHT SIDE OF TRUNK)
RED/GRN WIRE
RED/WHT WIRE
SPECIAL PURPOSE VEHICLE CONTROL MODULE
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (ON STEERING COLUMN,
VIO/WHT WIRE
YEL WIRE
Go to component -> Computer data lines circuit (1 of 2) -> SPECIAL PURPOSE VEHICLE CONTROL MODULE
