Volkswagen Passat B6 (2005-2010) front passenger's door control module (in front passenger's Wiring diagram
This page shows the only wiring diagram for the component.front passenger's door control module (in front passenger's, which is found in the car Volkswagen Passat B6 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram front passenger's door control module (in front passenger's (1 of 1)
ANTENNA
ANTENNA AMPLIFIER
ANTENNA AMPLIFIER 2
ANTENNA AMPLIFIER 3
BASE
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BRN WIRE
BRN/WHT WIRE
COMPUTER DATA LINES SYSTEM
DOOR
DRIVER'S OUTSIDE MIRROR
DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR)
FM FREQUENCY FILTER (-)
FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S
FRONT PASSENGER'S OUTSIDE MIRROR
FUSE 12
FUSE 12 (AT RIGHT END OF DASH)
FUSE 29
FUSE PANEL
GRN WIRE
HEATED REAR WINDOW
HOT AT ALL TIMES
HOT AT ALL TIMES FUSE PANEL
MIRROR HEATER
NCA WIRE
ORG/ WIRE
ORG/BRN WIRE
ORG/GRN WIRE
OUTSIDE MIRROR HEATING SWITCH
OUTSIDE MIRROR SWITCH
PREMIUM
RADIO ANTENNA 2
REAR WINDOW DEFOGGER RELAY
RED WIRE
RED/VIO WIRE
RED/YEL WIRE
SOUND SYSTEM
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE
VIO WIRE
YEL WIRE
Go to component -> Defoggers circuit -> FRONT PASSENGER'S DOOR CONTROL MODULE (IN FRONT PASSENGER'S
