Volkswagen Passat B6 (2005-2010) automatic distance control switch Wiring diagram
This page shows the only wiring diagram for the component.automatic distance control switch, which is found in the car Volkswagen Passat B6 (2005-2010). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram automatic distance control switch (1 of 1)
3.6L 2.0L
AIRBAG SPIRAL SPRING/RETURN SPRING (W/ SLIP RING)
AUTOMATIC DISTANCE CONTROL SWITCH
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/VIO WIRE
BRN WIRE
BRN/GRY WIRE
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SET BUTTON/ AUTOMATIC DISTANCE CONTROL BUTTON
CRUISE CONTROL SET SWITCH
CRUISE CONTROL SWITCH CRUISE CONTROL MAIN SWITCH
CRUISE CONTROL SYSTEM
FUSE
FUSE PANEL
GRN WIRE
GRN/BLU WIRE
GRN/GRY WIRE
GRY WIRE
HEADLAMP DIMMER/ FLASHER SWITCH
HORNS SYSTEM
HOT AT ALL TIMES
ORG/BLK WIRE
ORG/BRN WIRE
ORG/GRN WIRE
RED WIRE
RED/BLU WIRE
RED/GRY WIRE
RED/YEL WIRE
STEERING ANGLE SENSOR
STEERING COLUMN ELECTRONIC SYSTEMS CONTROL MODULE (ON STEERING COLUMN,
SUPPLEMENTAL RESTRAINTS SYSTEM
TRANSMISSION SYSTEM
TURN SIGNAL SWITCH
TURN SIGNAL SWITCH (HEADLIGHT DIMMER/FLASHER SWITCH)
VEHICLE ELECTRICAL SYSTEM CONTROL MODULE (BEHIND LEFT SIDE OF DASH)
VIO WIRE
WHT WIRE
WINDSHIELD WIPER/WASHER SWITCH
YEL WIRE
Go to component -> Steering column electronic systems control module circuit -> AUTOMATIC DISTANCE CONTROL SWITCH
