Car Wiring Diagrams for Heated seats circuit for Volkswagen Passat B5 facelift (2000-2005)

BLK WIRE BLU WIRE BRN WIRE DRIVER'S BACKREST HEATING ELEMENT DRIVER'S HEATED SEAT CONTROL MODULE DRIVER'S SEAT HEATING ELEMENT DRIVER'S SEAT TEMPER- ATURE SENSOR FUSE 44 FUSE 5 FUSE PANEL (UNDER LEFT SIDE OF DASH) GRN WIRE GRY WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN ON OR START LEFT REAR BACKREST HEATING ELEMENT LEFT REAR HEATED SEAT CONTROL MODULE LEFT REAR SEAT HEATING ELEMENT LEFT REAR SEAT TEMPER- ATURE SENSOR PASSENGER'S BACKREST HEATING ELEMENT PASSENGER'S HEATED SEAT CONTROL MODULE PASSENGER'S SEAT HEATING ELEMENT PASSENGER'S SEAT TEMPER- ATURE SENSOR REAR DRIVER SIDE OCCUPIED SENSOR SEAT SENSOR REAR PASSENGER SIDE OCCUPIED SENSOR SEAT SENSOR RED WIRE RED/WHT WIRE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR HEATED SEAT CONTROL MODULE RIGHT REAR SEAT HEATING ELEMENT RIGHT REAR SEAT TEMPER- ATURE SENSOR WHT WIRE YEL WIRE
