2.8l, manual a/c circuit for Volkswagen Passat B5 facelift (2000-2005)

A/C CLUTCH A/C CUT-OFF CONTROL MODULE (ON THIRTEENFOLD AUXILIARY RELAY PANEL) A/C DIODE A/C PRESSURE SWITCH (ON RIGHT SIDE OF A/C CONDENSER, BELOW RIGHT HEADLIGHT) A/C SWITCH AFTER-RUN COOLANT PUMP AMBIENT TEMPERATURE SWITCH BLK WIRE BLK/BLU WIRE BLK/BRN WIRE BLK/GRN WIRE BLK/GRY WIRE BLK/RED WIRE BLK/VIO WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/VIO WIRE BRN WIRE BRN/BLK WIRE BRN/BLU WIRE BRN/RED WIRE BRN/WHT WIRE BRN/YEL WIRE COOLANT FAN COOLANT FAN CONTROL (FC) A/C RELAY (ON EIGHTFOLD AUXILIARY RELAY PANEL) COOLANT FAN CONTROL (FC) THERMAL SWITCH (ON LOWER LEFT SIDE OF RADIATOR) COOLANT FC (FAN CONTROL) CONTROL MODULE DEFOGGER SYSTEM EIGHTFOLD AUXILIARY RELAY PANEL (UNDER LEFT SIDE OF DASH) FRESH AIR BLOWER (BEHIND RIGHT SIDE OF DASH, ON HVAC HOUSING) FRESH AIR BLOWER SERIES RESISTANCE WITH FUSE FRESH AIR BLOWER SWITCH FRESH/ RECIRC SWITCH FRESH/RECIRCULATING AIR DOOR SERVO MOTOR FUSE 25 FUSE 42 FUSE 51 FUSE PANEL (UNDER LEFT SIDE OF DASH) GRN WIRE GRN/YEL WIRE GRY WIRE GRY/BLU WIRE GRY/RED WIRE HEATER-A/C CONTROL PANEL HOT AT ALL TIMES HOT IN ACC OR RUN HOT W/ LOAD REDUCTION RELAY ENERGIZED INSTRUMENT CLUSTER OUTSIDE AIR TEMP SENSOR (FRONT OF A/C CONDENSER) RED WIRE RED/BLU WIRE RED/GRN WIRE RED/GRY WIRE RED/YEL WIRE YEL WIRE
