Volkswagen Passat B5 (1996-2001) speedo- meter vehicle speed sensor Wiring diagram
This page shows the only wiring diagram for the component.speedo- meter vehicle speed sensor, which is found in the car Volkswagen Passat B5 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram speedo- meter vehicle speed sensor (1 of 1)
1.8L ONLY
1995 VFTC
2.8L ONLY
ABS CONTROL MODULE
BATTERY
BLK WIRE
BRN WIRE
CD CHANGER UNIT
ENGINE COOLANT LEVEL SENSOR
ENGINE SPEED SENSOR
HEADLIGHT WASHER PUMP
HEATED OXYGEN SENSOR SHIELD
HORN SWITCH
IGNITION COIL
IGNITION COIL 1
IGNITION COIL 2
IGNITION COIL 3
IGNITION COIL 4
KICKDOWN SWITCH
KNOCK SENSOR #2
KNOCK SENSOR 1
MASS AIRFLOW SENSOR
MOTRONIC ENGINE CONTROL MODULE (ECM)
NCA WIRE
OXYGEN SENSOR SHIELD
POWER OUTPUT STAGE
RADIO
SECONDARY AIR INJECTION (AIR) PUMP MOTOR
SECONDARY AIR INJECTION (AIR) PUMP RELAY
SPEEDO- METER VEHICLE SPEED SENSOR
YEL WIRE
Go to component -> Ground distribution circuit (1 of 3) -> SPEEDO- METER VEHICLE SPEED SENSOR
