Volkswagen Passat B5 (1996-2001) rear lid unlocked warning light Wiring diagrams
This page contains all the electrical diagrams for the component. rear lid unlocked warning light, in which he is found in the car Volkswagen Passat B5 (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram rear lid unlocked warning light (1 of 2)
ALARM HORN (LEFT FRONT OF LUGGAGE COMPARTMENT)
ANTENNA
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BLU/GRY WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/GRY WIRE
BRN/RED WIRE
BRN/VIO WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CENTRAL LOCKING WARNING LIGHT (SAFE)
CIRCUIT BREAKER
COMPUTER DATA LINES SYSTEM
CONTROL MODULE
DECKLID CENTRAL LOCKING MOTOR (IN REAR LID LOCK/ LATCH MECHANISM)
DEFOGGER SYSTEM
DRIVER'S SIDE CENTRAL LOCKING LOCK UNIT
DRIVER'S SIDE INTERIOR LOCK SWITCH
EIGHT FOLD AUXILIARY RELAY PANEL (UNDER LEFT SIDE OF DASH)
FUSE
FUSE FUSE
FUSE PANEL (UNDER LEFT SIDE OF DASH) FUSE
GRN WIRE
GRN/BRN WIRE
GRY WIRE
GRY/BLU WIRE
HOOD ALARM SWITCH (PART OF HOOD LATCH)
HOT AT ALL TIMES
HOT IN ON OR START
IGNITION SWITCH
INSTRUMENT CLUSTER
INSTRUMENT CLUSTER SYSTEM
INTERIOR LIGHTS SYSTEM (LUGGAGE COMPT LIGHT SWITCH)
INTERIOR LIGHTS SYSTEM TRUNK, TAILGATE, FUEL DOORS SYSTEM
KEY SWITCH
NCA WIRE
NOT USED NOT USED
ORG/BRN WIRE
ORG/GRN WIRE
POWER TOPS SYSTEM
POWER WINDOWS SYSTEM, MIRRORS SYSTEM, TRUNK, TAILGATE, FUEL DOORS SYSTEM
RADIO, INTERIOR LIGHTS SYSTEM
REAR LID UNLOCKED WARNING LIGHT
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/BRN WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
STARTING/CHARGING SYSTEM
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
VIO/BLK WIRE
VIO/BLU WIRE
WHT WIRE
WHT/BLU WIRE
YEL WIRE
YEL/BLK WIRE
YEL/BRN WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Anti-theft circuit (1 of 2) -> REAR LID UNLOCKED WARNING LIGHT
