Volkswagen Passat B5 (1996-2001) passenger's backrest adjusting motor Wiring diagram
This page shows the only wiring diagram for the component.passenger's backrest adjusting motor, which is found in the car Volkswagen Passat B5 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram passenger's backrest adjusting motor (1 of 1)
BACKREST ADJUST
BLK WIRE
BLU WIRE
BRN WIRE
BWD
CIRCUIT BREAKER 44
CIRCUIT BREAKER 80
DOWN
DRIVER'S BACKREST ADJUSTING MOTOR
DRIVER'S POWER SEAT CIRCUIT BREAKER
DRIVER'S SEAT FORE/AFT ADJUSTING MOTOR
DRIVER'S SEAT FRONT HEIGHT ADJUSTING MOTOR
DRIVER'S SEAT REAR HEIGHT ADJUSTING MOTOR
DRIVER'S SEAT SWITCH
FORE/AFT ADJUST
FRONT HEIGHT ADJUST
GRN WIRE
HOT AT ALL TIMES
PASSENGER'S BACKREST ADJUSTING MOTOR
PASSENGER'S POWER SEAT CIRCUIT BREAKER
PASSENGER'S SEAT FORE/AFT ADJUSTING MOTOR
PASSENGER'S SEAT FRONT HEIGHT ADJUSTING MOTOR
PASSENGER'S SEAT REAR HEIGHT ADJUSTING MOTOR
PASSENGER'S SEAT SWITCH
REAR HEIGHT ADJUST
RED WIRE
WHT WIRE
YEL WIRE
Go to component -> Power seats circuit -> PASSENGER'S BACKREST ADJUSTING MOTOR
