Volkswagen Passat B5 (1996-2001) mirrors system, door locks system, trunk, tailgate, fuel doors system Wiring diagram
This page shows the only wiring diagram for the component.mirrors system, door locks system, trunk, tailgate, fuel doors system, which is found in the car Volkswagen Passat B5 (1996-2001). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mirrors system, door locks system, trunk, tailgate, fuel doors system (1 of 1)
BRN WIRE
DEFOGGER HEATING ELEMENT
DOOR LOCKS SYSTEM
DOOR LOCKS SYSTEM PASSENGER'S SIDE HEATED OUTSIDE MIRROR
DRIVER'S SIDE DOOR CONTROL MODULE (IN DRIVER'S DOOR)
DRIVER'S SIDE HEATED OUTSIDE MIRROR
FUSE 26
FUSE PANEL (UNDER LEFT SIDE OF DASH)
GRY/BLU WIRE
HEATED REAR WINDOW
HOT IN ON, FROM LOAD REDUCTION RELAY
ILLUM- INATION LAMP
MIRRORS SYSTEM, DOOR LOCKS SYSTEM, TRUNK, TAILGATE, FUEL DOORS SYSTEM
OFF
ON INDICATOR
ON ON OFF
ORG/GRN WIRE
PASSENGER'S SIDE DOOR CONTROL MODULE (IN PASSENGER'S DOOR)
REAR WINDOW DEFOGGER SWITCH
WAGON SEDAN
WHT WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Defogger circuit -> MIRRORS SYSTEM, DOOR LOCKS SYSTEM, TRUNK, TAILGATE, FUEL DOORS SYSTEM
