Volkswagen Passat B5 (1996-2001) left rear taillight assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left rear taillight assembly, in which he is found in the car Volkswagen Passat B5 (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left rear taillight assembly wiring diagram (1 of 3)
Go to component -> Back-up lamps circuit -> LEFT REAR TAILLIGHT ASSEMBLY
left rear taillight assembly wiring diagram (2 of 3)
BLK WIRE
BLK/GRN WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BRAKE LIGHT SWITCH
BRAKE TAIL
BRAKE/
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE (UNDER DRIVER'S SEAT, CARPET)
CONTROL MODULE
EMERGENCY FLASHER SWITCH
FUSE
FUSE PANEL (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/RED WIRE
GRY WIRE
GRY/RED WIRE
HIGH MOUNT BRAKE LIGHT
HOT AT ALL TIMES
HOT IN ON
INSTRUMENT CLUSTER
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT REAR TAILLIGHT ASSEMBLY
LEFT RIGHT TURN IND TURN IND
LEFT SIDE TURN SIGNAL LIGHT
LICENSE PLATE LIGHTS
LIGHT SWITCH
LOAD REDUCTION RELAY
OFF HEAD PARK
RED WIRE
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT LEFT
RIGHT REAR TAILLIGHT ASSEMBLY
RIGHT SIDE TURN SIGNAL LIGHT
SOLID STATE
TAIL
THIRTEEN -FOLD AUXILIARY RELAY PANEL
TURN
TURN SIGNAL SWITCH
WHT WIRE
YEL WIRE
Go to component -> Exterior lamps circuit -> LEFT REAR TAILLIGHT ASSEMBLY
left rear taillight assembly wiring diagram (3 of 3)
2.8L ONLY
A/C PRESSURE SWITCH AFTER-
ALARM HORN
AUTOMATIC DAY/NIGHT INTERIOR MIRROR
BLK WIRE
BRN WIRE
COMFORT SYSTEM CENTRAL CONTROL MODULE
COOLANT FAN (1.8L ONLY)
COOLANT FAN CONTROL MODULE (2.8L ONLY)
COOLANT FAN CONTROL THERMAL SWITCH
COOLANT PUMP (2.8L ONLY)
DRIVER'S SEAT SWITCH (W/O MEMORY SEATS)
DRIVER'S SIDE DOOR CONTROL MODULE
DUAL HORNS
FROM PARKING BRAKE WARNING LIGHT SWITCH (DIAGRAM
FRONT INTERIOR LIGHT
FUEL PUMP
FUEL TANK LID UNLOCK MOTOR
HEATED REAR WINDOW
HEATED REAR WINDOW (WAGON)
HIGH MOUNT BRAKE LIGHT
HOOD ALARM SWITCH
LEFT FRONT TURN SIGNAL, SIDE MARKER LIGHT
LEFT HEADLIGHT ASSEMBLY
LEFT MAKE-UP MIRROR LIGHT SWITCH
LEFT REAR DOOR CONTROL MODULE SEDAN ONLY SEDAN ONLY
LEFT REAR READING LIGHT
LEFT REAR TAILLIGHT ASSEMBLY
LEFT SIDE TURN SIGNAL LIGHT
LICENSE PLATE LIGHTS
LUGGAGE COMPARTMENT LIGHT SWITCH (WAGON)
LUGGAGE COMPARTMENT LIGHT SWITCH TRUNK LID CENTRAL LOCKING SWITCH
MEMORY SEAT CONTROL MODULE
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
NCA WIRE
OUTLET (SEDAN ONLY)
OUTSIDE AIR TEMPERATURE SENSOR (EARLY PRODUCTION)
PASSENGER'S SEAT SWITCH (W/O MEMORY SEATS)
PASSENGER'S SIDE DOOR CONTROL MODULE
POWER SUNROOF CONTROL MODULE
RAIN SENSOR
REAR LID REMOTE UNLOCK MOTOR
REAR WINDOW WIPER MOTOR (WAGON)
REMOTE FUEL TANK DOOR SWITCH
RIGHT FRONT TURN SIGNAL/ SIDE MARKER LIGHT
RIGHT HEADLIGHT ASSEMBLY
RIGHT MAKE-UP MIRROR LIGHT SWITCH
RIGHT REAR DOOR CONTROL MODULE
RIGHT REAR READING LIGHT
RIGHT REAR TAILLIGHT ASSEMBLY
RIGHT SIDE TURN SIGNAL LIGHT
RUN WIRE
SELECTOR LEVER WARNING LIGHT (P/N)
SOCKET
TRANSMISSION CONTROL MODULE (TCM)
WAGON ONLY
Go to component -> Ground distribution circuit (3 of 3) -> LEFT REAR TAILLIGHT ASSEMBLY
