Volkswagen Passat B5 (1996-2001) left rear central locking lock unit Wiring diagrams
This page contains all the electrical diagrams for the component. left rear central locking lock unit, in which he is found in the car Volkswagen Passat B5 (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
left rear central locking lock unit wiring diagram (1 of 2)
BLK WIRE
BLK/BLU WIRE
BLK/GRY WIRE
BLU WIRE
BRN WIRE
BRN/BLK WIRE
BRN/BLU WIRE
BRN/GRN WIRE
BRN/YEL WIRE
GRN WIRE
GRY WIRE
LEFT REAR CENTRAL LOCKING LOCK UNIT
MIRRORS SYSTEM
ORG/BRN WIRE
ORG/GRN WIRE
PASSENGER'S SIDE CENTRAL LOCKING LOCK UNIT
PASSENGER'S SIDE INTERIOR LOCK SWITCH
RED WIRE
RED/BLU WIRE
RED/GRN WIRE
RED/WHT WIRE
RED/YEL WIRE
RIGHT REAR CENTRAL LOCKING LOCK UNIT
TRUNK LID CENTRAL LOCKING SWITCH (IN REAR LID WITH LOCK/ LATCH MECHANISM)
YEL WIRE
YEL/BLU WIRE
YEL/GRN WIRE
Go to component -> Anti-theft circuit (2 of 2) -> LEFT REAR CENTRAL LOCKING LOCK UNIT
