Volkswagen Passat B5 (1996-2001) left front traction control switch-over valve Wiring diagrams
This page contains all the electrical diagrams for the component. left front traction control switch-over valve, in which he is found in the car Volkswagen Passat B5 (1996-2001). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left front traction control switch-over valve (1 of 2)
ABS CONTROL MODULE (LEFT FRONT INNER FENDER PANEL)
ABS RETURN FLOW PUMP
ABS RETURN FLOW PUMP RELAY
ABS SOLENOID VALVE RELAY
ABS WARNING IND
BLK WIRE
BLK/BLU WIRE
BRAKELIGHT SWITCH (BELOW LEFT SIDE OF DASH)
BRN WIRE
CLIMATRONIC CONTROL MODULE
CONTROL MODULE WITH INDICATOR UNIT
DATA LINK CONNECTOR
FUSE 13
FUSE 53
FUSE 7
FUSE PANEL (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
HOT AT ALL TIMES
HOT IN ON, START
INSTRUMENT CLUSTER
LEFT FRONT ABS INLET VALVE
LEFT FRONT ABS OUTLET VALVE
LEFT FRONT TRACTION CONTROL OUTLET VALVE
LEFT FRONT TRACTION CONTROL SWITCH-OVER VALVE
LEFT REAR ABS INLET VALVE
LEFT REAR ABS OUTLET VALVE
LEFT REAR ABS WHEEL SPEED SENSOR (ON BACK OF LEFT REAR WHEEL BEARING ASSEMBLY)
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT ABS INLET VALVE
RIGHT FRONT ABS OUTLET VALVE
RIGHT FRONT TRACTION CONTROL OUTLET VALVE
RIGHT FRONT TRACTION CONTROL SWITCH-OVER VALVE
RIGHT REAR ABS INLET VALVE
RIGHT REAR ABS OUTLET VALVE
RIGHT REAR ABS WHEEL SPEED SENSOR (ON BACK OF RIGHT REAR WHEEL BEARING ASSEMBLY)
THIRTEEN-FOLD AUXILIARY RELAY PANEL (UNDER LEFT SIDE OF DASH)
W/ CLIMATRONIC AIR CONDITIONING
WHT WIRE
YEL WIRE
YEL/RED WIRE
Go to component -> Anti-lock brake circuits, without traction control -> LEFT FRONT TRACTION CONTROL SWITCH-OVER VALVE
Wiring diagram left front traction control switch-over valve (2 of 2)
ABS CONTROL MODULE (LEFT FRONT INNER FENDER PANEL)
ABS RETURN FLOW PUMP
ABS RETURN FLOW PUMP RELAY
ABS SOLENOID VALVE RELAY
ABS WARNING IND
ANTI-SLIP CONTROL SWITCH
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLU WIRE
BRAKELIGHT SWITCH (BELOW LEFT SIDE OF DASH)
BRN WIRE
CLIMATRONIC CONTROL MODULE
CONTROL MODULE WITH INDICATOR UNIT
DATA LINK CONNECTOR
FUSE 13
FUSE 53
FUSE 7
FUSE PANEL (UNDER LEFT SIDE OF DASH)
GRN WIRE
GRN/BLK WIRE
GRN/BLU WIRE
GRN/BRN WIRE
GRN/RED WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON, START
INSTRUMENT CLUSTER
LEFT FRONT ABS INLET VALVE
LEFT FRONT ABS OUTLET VALVE
LEFT FRONT TRACTION CONTROL OUTLET VALVE
LEFT FRONT TRACTION CONTROL SWITCH-OVER VALVE
LEFT REAR ABS INLET VALVE
LEFT REAR ABS OUTLET VALVE
LEFT REAR ABS WHEEL SPEED SENSOR (ON BACK OF LEFT REAR WHEEL BEARING ASSEMBLY)
MOTRONIC ENGINE CONTROL MODULE (LEFT REAR CORNER OF ENGINE COMPT)
RED/BLK WIRE
RED/YEL WIRE
RIGHT FRONT ABS INLET VALVE
RIGHT FRONT ABS OUTLET VALVE
RIGHT FRONT TRACTION CONTROL OUTLET VALVE
RIGHT FRONT TRACTION CONTROL SWITCH-OVER VALVE
RIGHT REAR ABS INLET VALVE
RIGHT REAR ABS OUTLET VALVE
RIGHT REAR ABS WHEEL SPEED SENSOR (ON BACK OF RIGHT REAR WHEEL BEARING ASSEMBLY)
THIRTEEN-FOLD AUXILIARY RELAY PANEL (UNDER LEFT SIDE OF DASH)
TRACTION CONTROL IND
TRANSMISSION CONTROL MODULE (PASSENGER'S SIDE FLOOR CAVITY)
VIO/BLK WIRE
W/ CLIMATRONIC AIR CONDITIONING
WHT WIRE
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> Anti-lock brake circuits, with traction control -> LEFT FRONT TRACTION CONTROL SWITCH-OVER VALVE
