Car Wiring Diagrams for Headlights circuit for Volkswagen Passat B4 (1993-1997)

B/3 BATTERY BLK/YEL WIRE BRN WIRE CONTROL MODULE WITH DISPLAY UNIT DIMMER FLASH HI FOG LIGHT INDICATOR FOG LIGHT RELAY FOG LIGHT SWITCH FUSE 1 FUSE 10 FUSE 11 FUSE 12 FUSE 2 FUSE/ RELAY PANEL GRY WIRE GRY/BLK WIRE GRY/BLU WIRE GRY/GRN WIRE GRY/RED WIRE GRY/YEL WIRE HEADLIGHT DIMMER/ FLASHER SWITCH HEADLIGHT SWITCH HEADLIGHT SWITCH LIGHT HEADLIGHT WASHER SYSTEM RELAY HIGH BEAM INDICATOR HOT AT ALL TIMES IGNITION SWITCH ILLUMINATION INSTRUMENT CLUSTER J/1 J/2 J/3 J/4 LEFT FOG LIGHT LEFT HEADLIGHT INTERIOR LIGHTS SYSTEM LIGHT SWITCH LOCK NCA WIRE NOT USED REAR FOG LIGHT INDICATOR P/1 PARK LIGHT INDICATOR PL PARK LIGHT SWITCH R/2 R/5 R/6 R/7 R/8 R/9 REAR FOG LIGHT SWITCH RED WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FOG LIGHT RIGHT HEADLIGHT SERIES RESISTANCE (W/ DRL) SOLID STATE WHT WIRE WHT/BLK WIRE WHT/YEL WIRE YEL WIRE YEL/BLK WIRE
