Volkswagen Passat B4 (1993-1997) motronic engine control module (engine compt, left of center plenum) wiring diagram
This page shows the only wiring diagram for the component.motronic engine control module (engine compt, left of center plenum), which is found in the car Volkswagen Passat B4 (1993-1997). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
motronic engine control module (engine compt, left of center plenum) wiring diagram (1 of 1)
1995 VFTC
ANTI-LOCK BRAKE SYSTEM
BLK WIRE
BLK/BLU WIRE
BLK/GRN WIRE
BLK/GRY WIRE
BLK/RED WIRE
BLK/WHT WIRE
BLU WIRE
BLU/WHT WIRE
BLU/YEL WIRE
BRAKE LIGHT SWITCH (ABOVE BRAKE PEDAL)
BRN WIRE
BRN/BLU WIRE
BRN/RED WIRE
BRN/WHT WIRE
D/8
DATA LINK CONNECTOR (BEHIND CONSOLE)
E/3
E/4
F/6
F/9
FUSE 14
FUSE 20
FUSE 51
FUSE/RELAY PANEL (LEFT I/P)
GRN WIRE
GRN/BLK WIRE
GRN/WHT WIRE
GRY WIRE
GRY/BLK WIRE
GRY/BLU WIRE
GRY/WHT WIRE
HOT AT ALL TIMES
HOT IN ON OR START
INSTRUMENT CLUSTER SYSTEM
K/4
KICK DOWN SWITCH
MOTRONIC ENGINE CONTROL MODULE (ENGINE COMPT, LEFT OF CENTER PLENUM)
MULTI-FUNCTION TRANSMISSION RANGE SWITCH (REAR OF TRANSMISSION CASE)
NCA WIRE
PARK/ NEUTRAL POSITION RELAY
RED WIRE
RED/BLK WIRE
RED/WHT WIRE
RED/YEL WIRE
SHIFT LOCK SOLENOID
SOLENOID VALVES
SOLID STATE
STARTING/ CHARGING SYSTEM
TRANSMISSION CONTROL MODULE (BELOW REAR SEAT)
TRANSMISSION FLUID TEMPERATURE SENSOR
VALVE BODY
VEHICLE SPEED SENSOR (LEFT FRONT OF TRANS)
VIO/BLK WIRE
WHT WIRE
WHT/GRN WIRE
Y/2
YEL WIRE
YEL/BLU WIRE
YEL/RED WIRE
Go to component -> A/t circuit -> MOTRONIC ENGINE CONTROL MODULE (ENGINE COMPT, LEFT OF CENTER PLENUM)
