Volkswagen Passat B4 (1993-1997) mirror adjustment switch Wiring diagrams
This page contains all the electrical diagrams for the component. mirror adjustment switch, in which he is found in the car Volkswagen Passat B4 (1993-1997). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
mirror adjustment switch wiring diagram (1 of 3)
ALARM HOOD SWITCH
ALARM HORN
ALARM SYSTEM CONTROL MODULE
AUTOMATIC TRANSMISSION CONSOLE LIGHT
B+4
BLK WIRE
BRN WIRE
CRUISE CONTROL MODULE
DRIVER'S BACKREST HEAT ELEMENT
DRIVER'S SEAT HEATER CONTROL MODULE
DRIVER'S SEAT HEATER TEMPERATURE SENSOR/SEAT HEAT ELEMENT
DRIVER'S SIDE HEATED MIRROR
DRIVER'S SIDE MIRROR MAGNETIC CLUTCH
FRONT POWER WINDOW SWITCH
FUSE/ RELAY PANEL
HEADLIGHT WASHER SYSTEM RELAY
KICK DOWN SWITCH
LEFT FRONT CENTRAL LOCKING SYSTEM SWITCH
LEFT FRONT POWER WINDOW CONTROL MODULE
LEFT REAR POWER WINDOW CONTROL MODULE
LEFT REAR POWER WINDOW SWITCH
LEFT WASHER NOZZLE HEATER
MIRROR ADJUSTMENT SWITCH
MULTI-FUNCTION TRANSMISSION RANGE SWITCH
PARK/ NEUTRAL POSITION RELAY
PASSENGER'S BACKREST HEAT ELEMENT
PASSENGER'S HEATER TEMPERATURE SENSOR/SEAT HEAT ELEMENT
PASSENGER'S SEAT HEAT REGULATING SWITCH
PASSENGER'S SEAT HEATER CONTROL MODULE
PASSENGER'S SIDE HEATED MIRROR
PASSENGER'S SIDE MIRROR MAGNETIC CLUTCH
REAR POWER WINDOWS CONSOLE SWITCH
RIGHT FRONT CENTRAL LOCKING SYSTEM SWITCH
RIGHT FRONT POWER WINDOW CONTROL MODULE
RIGHT FRONT WINDOW SWITCH
RIGHT REAR POWER WINDOW CONTROL MODULE
RIGHT REAR POWER WINDOW SWITCH
RIGHT WASHER NOZZLE HEATER
TRANSMISSION CONTROL MODULE
Go to component -> Ground distribution circuit (3 of 4) -> MIRROR ADJUSTMENT SWITCH
mirror adjustment switch wiring diagram (2 of 3)
1/86
A/T M/T
AIRBAG CONTROL MODULE
ALARM SYSTEM CONTROL MODULE
BLK WIRE
BLK/BLU WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
COOLANT FAN CONTROL MODULE
CRUISE CONTROL SWITCH SEAT BELT WARNING SYSTEM
D/11
D/8
D/9
DRIVER'S SEAT REGULATING HEATER SWITCH
DUAL HORN RELAY
DUAL HORNS
F/6
FROM FUSE/ RELAY PANEL
FUEL PUMP RELAY
FUSE 13
FUSE 14
FUSE 15
FUSE 16
FUSE 17
FUSE/ RELAY PANEL (UNDER LEFT SIDE OF DASH)
GLOVE COMPARTMENT LIGHT BRAKE/ PARKING BRAKE INDICATOR
HEADLIGHT DIMMER/ FLASHER SWITCH
IGNITION SWITCH
INSTRUMENT CLUSTER
INTERIOR LIGHT WITH DELAY SWITCH SUNROOF SWITCH
LEFT WASHER NOZZLE HEATER, RIGHT WASHER NOZZLE HEATER
LOCK
M/5
MIRROR ADJUSTMENT SWITCH
MOTRONIC ENGINE CONTROL MODULE
MULTI- FUNCTION SWITCH
NCA WIRE
PASSENGER'S SEAT HEATER CONTROL UNIT DRIVER'S SEAT HEATER CONTROL UNIT
POSITIVE CRANKCASE VENTILATION HEATING ELEMENT
Q/4 X/4 E/2
RED WIRE
RED/BLK WIRE
RED/YEL WIRE
RELAY
RIGHT FRONT POWER WINDOW CONTROL MODULE LEFT FRONT POWER WINDOW CONTROL MODULE
SHIFT LOCK SOLENOID TRANSMISSION CONTROL MODULE
THIRD SPEED COOLANT FAN CONTROL THERMO- SWITCH (3-SPEED)
TO FUSE/ RELAY PANEL (15) (DIAGRAM 4 OF 4)
TO FUSE/RELAY PANEL
TO FUSE/RELAY PANEL LOAD REDUCTION RELAY (DIAGRAM 1 OF 4)
TV 4 JUNCTION CONNECTOR (BEHIND FUSE/ RELAY PANEL)
TV 5 JUNCTION CONNECTOR (BEHIND FUSE/ RELAY PANEL)
WHT WIRE
YEL WIRE
Go to component -> Power distribution circuit (2 of 4) -> MIRROR ADJUSTMENT SWITCH
mirror adjustment switch wiring diagram (3 of 3)
BLK WIRE
BLU WIRE
BLU/BLK WIRE
BLU/WHT WIRE
BRN WIRE
DEFOGGER SYSTEM
DRIVER'S SIDE HEATED MIRROR
DRIVER'S SIDE MIRROR ADJUSTMENT MOTOR
DRIVER'S SIDE MIRROR MAGNETIC CLUTCH
FUSE 16
FUSE/ RELAY PANEL (BEHIND LEFT SIDE OF DASH)
HOT IN RUN OR START
M/5
MIRROR ADJUSTMENT SWITCH
MIRROR SELECTOR SWITCH
NCA WIRE
PASSENGER'S SIDE HEATED MIRROR
PASSENGER'S SIDE MIRROR ADJUSTMENT MOTOR
PASSENGER'S SIDE MIRROR MAGNETIC CLUTCH
PLUS CONNECTION (15) (IN REAR WIRING HARNESS)
WHT WIRE
WHT/GRN WIRE
WHT/YEL WIRE
YEL WIRE
Go to component -> Power mirrors circuit -> MIRROR ADJUSTMENT SWITCH
