Heated seats circuit for Volkswagen Passat (North America) II (2019-2022)

A/C CONTROL MODULE (CENTER OF DASH) AUTOMATIC A/C BLK WIRE BLK/RED WIRE BLU WIRE BLU/WHT WIRE BRN WIRE BRN/BLK WIRE CLIMATRONIC CONTROL MODULE COMPUTER DATA LINES SYSTEM DRIVER BACKREST HEATING ELEMENT DRIVER SEAT HEATING ELEMENT, TEMPERATURE SENSOR FRONT PASSENGER BACKREST HEATING ELEMENT FRONT SEAT HEATING CONTROL MODULE FUSE 48 FUSE 50 FUSE 9 FUSE PANEL C GRN WIRE GRN/RED WIRE GRY WIRE HEATING ELEMENT HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED LEFT FRONT SEAT COUPLING STATION LEFT SEAT HEATING BUTTON MANUAL A/C ORG/BRN WIRE ORG/GRN WIRE PASSENGER OCCUPANT DETECTION SYSTEM CONTROL MODULE RED WIRE RED/GRN WIRE RED/WHT WIRE RED/YEL WIRE RIGHT FRONT SEAT COUPLING STATION RIGHT SEAT HEATING BUTTON SUPPLEMENTAL RESTRAINTS SYSTEM TEMPERATURE SENSOR VEHICLE ELECTRICAL SYSTEM CONTROL MODULE VIO WIRE VIO/BLK WIRE VIO/BLU WIRE W/ POWER DRIVER SEAT ADJUSTER W/O POWER DRIVER SEAT ADJUSTER WHT WIRE

BLK/BLU WIRE BLU/VIO WIRE BLU/WHT WIRE BRN WIRE FUSE 13 FUSE 34 FUSE PANEL C GRY WIRE HOT AT ALL TIMES HOT W/ TERMINAL 15 RELAY ENERGIZED LEFT REAR BACKREST HEATING ELEMENT LEFT REAR BENCH SEAT HEATING ELEMENT LEFT REAR SEAT HEATING BUTTON REAR SEAT HEATING CONTROL MODULE RED/BLK WIRE RED/BLU WIRE RIGHT REAR BACKREST HEATING ELEMENT RIGHT REAR BENCH SEAT HEATING ELEMENT RIGHT REAR SEAT HEATING BUTTON VIO/BLU WIRE WHT WIRE WHT/RED WIRE WHT/YEL WIRE
