Parking assistant circuit, w/o parallel parking for Volkswagen Passat (North America) II (2019-2022)

BLK/BLU WIRE BLU/WHT WIRE BRN WIRE BRN/WHT WIRE COMPUTER DATA LINES SYSTEM FRONT PARKING AID WARNING BUZZER FUSE 13 FUSE PANEL C GRN/WHT WIRE HOT W/ TERMINAL 15 RELAY ENERGIZED LEFT FRONT CENTER PARKING AID SENSOR LEFT FRONT COUPLING POINT ON BUMPER LEFT FRONT PARKING AID SENSOR ORG/BLK WIRE ORG/BRN WIRE PARKING AID CONTROL MODULE REAR PARKING AID WARNING BUZZER RED WIRE RED/BLU WIRE RED/GRN WIRE RED/WHT WIRE RIGHT FRONT CENTER PARKING AID SENSOR RIGHT FRONT PARKING AID SENSOR VIO/BLU WIRE VIO/GRN WIRE VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE

BLU/WHT WIRE BRN WIRE BRN/WHT WIRE BULB BUTTON GRN/WHT WIRE GRY WIRE ILLUMINATION IND LAMP LEFT REAR CENTER PARKING AID SENSOR LEFT REAR PARKING AID SENSOR PARKING AID PARKING AID BUTTON PUSH BUTTON RED WIRE RED/WHT WIRE RIGHT COUPLING POINT IN LUGGAGE COMPARTMENT RIGHT REAR CENTER PARKING AID SENSOR RIGHT REAR PARKING AID SENSOR VIO/GRY WIRE VIO/RED WIRE VIO/WHT WIRE WHT WIRE
